Epiphan 4K Feature Add-On for Pearl-2 Base Video Mixer Upgrade License
Product Overview
The Epiphan 4K Feature Add-On is a one-time upgrade license that enables 4K encoding and streaming on the Pearl-2 Base video mixer. This Pearl-2 4K upgrade license lets AV teams encode 4K content, build a 4K program from multiple camera inputs, and use the Pearl-2 4K output ports. It applies to Pearl-2 Base units purchased before April 5, 2026; 4K capability now ships standard on current Pearl-2 hardware.
Product Description
This Epiphan Pearl-2 4K feature add-on activates the full 4K workflow on an existing Pearl-2 Base video mixer (sold separately). Once licensed, the Pearl-2 can encode and stream a 4K program comprised of up to two 4K and two HD or IP camera inputs, drive 4K output ports, and optionally downscale UHD 4K to 1080p for delivery. The license also supports cropping a single 4K view into several 1080p or 720p regions, letting operators switch between virtual cameras directly in the Pearl-2 switcher interface.
The add-on is intended for integrators and AV teams that deployed Pearl-2 Base hardware before 4K became a standard feature and now need ultra-high-definition capture, recording, and streaming. Activation is a one-time process completed through the Pearl-2 web portal, with no additional hardware required. For new deployments, the Pearl-2 Base already includes 4K, so this license is specifically for upgrading earlier units in the field.
Key Features
- 4K encoding and streaming — Enables full 4K encoding and streaming on a Pearl-2 Base that was not factory-equipped for 4K.
- Multi-source 4K program — Builds and streams a single 4K program from up to two 4K and two HD or IP camera inputs.
- 4K output ports — Enables the Pearl-2 4K output ports for connection to 4K-capable displays and recorders.
- UHD to 1080p downscaling — Optionally downscales UHD 4K sources to 1080p for streaming to standard CDNs.
- Virtual camera cropping — Crops a single 4K view into multiple 1080p or 720p regions that operators switch between as virtual cameras.
- Synchronized 4-up program — Combines up to four HD video sources into one synchronized live 4K video program.
- One-time activation — Activates permanently through the Pearl-2 web portal with no recurring fee or added hardware.
Typical Applications
- Lecture capture and classroom recording where a 4K camera and 4K slide presentation are combined into one program.
- Live event and broadcast production using a single stationary 4K camera to simulate multiple virtual HD cameras.
- House of worship and auditorium streaming that downscales 4K sources to Full HD for live delivery.
- Multi-camera environments that encode a UHD 4K collage from four HD video sources.
Technical Specifications
| SKU | ESP1205 |
| Product type | Software upgrade license (one-time activation) |
| Compatible hardware | Epiphan Pearl-2 Base Video Mixer (sold separately) |
| Capability enabled | 4K encoding, streaming, and 4K output ports |
| Maximum inputs in 4K program | Up to two 4K and two HD or IP camera inputs |
| Downscaling | Optional UHD 4K to 1080p |
| Activation method | One-time activation via Pearl-2 web portal |
| Applies to | Pearl-2 Base units purchased before April 5, 2026 |
Frequently Asked Questions
Which hardware does this license work with?
It works specifically with the Epiphan Pearl-2 Base Video Mixer, sold separately. It is not for Pearl Nano or other Pearl models.
Do I still need this if I am buying a new Pearl-2?
No. 4K now ships standard on current Pearl-2 hardware. This license is intended for Pearl-2 Base units purchased before April 5, 2026.
How is the license activated?
Activation is a one-time process completed through the Pearl-2 web portal. No additional hardware is required.
What does the 4K program support?
Once activated, the Pearl-2 can encode and stream a 4K program built from up to two 4K and two HD or IP camera inputs, and can drive the unit's 4K output ports.
Can I stream 4K sources at 1080p?
Yes. The add-on supports optional downscaling of UHD 4K sources to 1080p for streaming to standard 4K-capable or HD CDNs.
How do I purchase this upgrade for my AV system?
Add the license to your order on creationnetworks.net. Pair it with the Pearl-2 Base if you do not already own the host hardware.
