Eaton SMART3000RM2UN – 3kVA 2U Rack/Tower UPS

Product Overview

The Eaton SMART3000RM2UN is a high-capacity rackmount UPS built for AV racks, server rooms, and telecommunications closets that carry heavier equipment loads than a standard 1500VA unit can support. Rated at 3000VA, this 3000VA rackmount UPS for AV rack installations delivers pure sine wave output in both line and battery modes, protecting sensitive processors, amplifiers, and network gear from clean power interruptions. Its 2U line-interactive UPS with LCD design makes it a strong fit for broadcast studios, large boardrooms, and auditoriums running substantial AV equipment loads that need dependable, unity-power-factor backup.

Product Description

The SMART3000RM2UN is a line-interactive UPS with built-in automatic voltage regulation that corrects both slight under-voltages and severe brownout conditions using two separate levels of voltage boost, a configuration suited to buildings with historically poor utility power quality. Its seven-outlet configuration includes one L5-30R outlet for high-current equipment and six 5-20R outlets split across two independently switchable load banks, giving AV integrators the flexibility to shed non-critical loads during an outage while keeping essential broadcast or conferencing equipment running. The interactive LCD interface reports operating mode plus detailed UPS and site-power data, and also enables on-unit setup and configuration changes without external software. Transfer from line to battery power happens within milliseconds, and the unit operates at 98 percent line-mode efficiency, reducing heat generation and operating cost in equipment rooms with limited cooling. Communication options include a USB port, DB9 serial port, and a pre-installed WEBCARDLX network management card for remote monitoring across a facility's UPS fleet. The 72VDC VRLA battery set is hot-swappable and user-replaceable, minimizing downtime during battery service on equipment supporting mission-critical broadcast or commercial meeting space systems.

Key Features

• 3000VA/3000W Unity Power Factor Output — Delivers full-rated wattage output for demanding AV and network equipment loads.
• Pure Sine Wave in Line and Battery Modes — Provides clean power to sensitive processors and amplifiers under all operating conditions.
• Seven Managed Outlets Across Two Load Banks — Includes one L5-30R and six 5-20R outlets for flexible load shedding during outages.
• Dual-Stage Automatic Voltage Regulation — Corrects both minor under-voltages and severe brownouts without switching to battery.
• 98% Line-Mode Efficiency — Reduces heat output and operating costs in equipment rooms with limited cooling capacity.
• Hot-Swappable 72VDC Battery Set — Allows battery replacement without powering down connected equipment.
• Pre-Installed WEBCARDLX Network Card — Enables remote monitoring of UPS status and site power across a facility.

Typical Applications

• Broadcast studio equipment racks requiring clean, high-capacity power
• Boardroom AV racks with heavier processor and amplifier loads
• Auditorium sound and lighting control racks
• Government space server and AV equipment rooms
• Commercial meeting space installations with consolidated AV/IT racks

Technical Specifications

Frequently Asked Questions

Can the SMART3000RM2UN power multiple pieces of broadcast or AV equipment on separate circuits?

Yes. It provides seven managed outlets, including two independently switchable load banks, allowing non-critical equipment to be shed separately from mission-critical gear during an outage.

Does this UPS fit in a standard 19-inch AV rack?

Yes, it ships as a 2U rack/tower unit with included mounting hardware and tower stands for either rack or freestanding installation.

How long will it run connected equipment during an outage?

Runtime is rated at 3 minutes at full 3000W load and 9 minutes at half load, providing enough time for orderly shutdown or generator transfer in most facilities.

Can the battery be replaced without shutting down connected equipment?

Yes, the 72VDC VRLA battery set is hot-swappable and user-replaceable, allowing service without interrupting power to connected loads.

Does it support remote monitoring for a multi-room AV or broadcast facility?

Yes, it includes a pre-installed WEBCARDLX network management card along with USB and DB9 serial ports for remote monitoring.

What warranty applies to this UPS?

It carries a 2-year warranty, extendable to 3 years with product registration, plus $250,000 in connected equipment insurance.

Can Creation Networks help size this UPS against my actual AV rack load?

Yes, our team can review your equipment list and total wattage draw to confirm the SMART3000RM2UN is correctly sized for your installation.
