Eaton PDUMH30ATNET – Switched ATS PDU, 2U, TAA

Product Overview

The Eaton PDUMH30ATNET is a 2.9kW single-phase switched automatic transfer switch PDU with 2 120V L5-30P inputs, delivering power across 24 5-15/20R and 1 L5-30R outlets in a 2U, TAA-compliant rack-mount design. It combines automatic transfer switching between two 120V input sources with switched outlet control, allowing IT staff to remotely turn individual outlets on or off. This switched ATS PDU is designed for network IT and data center racks that need both power redundancy and outlet-level remote control.

Product Description

Racks that need both power source redundancy and remote outlet control benefit from a PDU that combines automatic transfer switching with switched outlet functionality, which is exactly what the PDUMH30ATNET delivers. With two 120V L5-30P inputs, the unit provides automatic failover between primary and secondary power sources, helping protect connected equipment from a single source outage. Its switched design extends beyond basic ATS protection by giving IT staff the ability to remotely control 24 5-15/20R outlets and 1 L5-30R outlet, useful for remotely power-cycling unresponsive equipment or scheduling outlet-level power sequencing without needing to physically access the rack. The 2U rack-mount form factor accommodates the outlet count and switching electronics while remaining a manageable footprint in a standard 19-inch rack. TAA compliance makes this PDU eligible for GSA Schedule and other federal procurement contracts, an important consideration for government and education customers. This combination of dual-source ATS protection and remote switched outlet control makes the PDUMH30ATNET well suited for data center racks, network operations centers, and IT environments where both uptime protection and remote equipment control are operational priorities.

Key Features

• Automatic Transfer Switching — provides redundant failover between two 120V L5-30P input sources.
• Switched Outlet Control — enables remote on/off control of individual outlets for power cycling or sequencing.
• 24 5-15/20R and 1 L5-30R Outlets — supports a large mix of standard rack and 120V equipment.
• 2U Rack-Mount Form Factor — fits standard 19-inch racks while housing dual-input switching electronics.
• TAA-Compliant — eligible for GSA Schedule and other federal procurement contracts.

Typical Applications

• Data center racks requiring redundant power with remote outlet control
• Network operations centers needing remote power-cycling capability
• Government space and federal facility racks requiring TAA-compliant switched PDUs

Technical Specifications

Frequently Asked Questions

What does switched outlet control allow me to do?

It allows IT staff to remotely turn individual outlets on or off, useful for power-cycling unresponsive equipment without physically accessing the rack.

Does this PDU protect against a single power source failure?

Yes, it includes automatic transfer switching between its two 120V L5-30P input sources.

Is this PDU eligible for federal procurement?

Yes, the PDUMH30ATNET is TAA-compliant, making it eligible for GSA Schedule and other federal procurement contracts.

How many outlets does this PDU provide?

It provides 24 5-15/20R outlets and 1 L5-30R outlet.

What is the warranty on this product?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.

Can Creation Networks help set up remote outlet switching?

Yes, our team can assist with initial configuration guidance for the PDU's network and switching interface.
