Eaton PDUMH20NET2LX – Switched 1.9kW PDU, 1U, LX Interface

Product Overview

The Eaton PDUMH20NET2LX is a switched, network-managed 1U rack PDU built for IT applications that need remote outlet control without an on-site visit. Its eight switched NEMA 5-15/20R outlets and Java-free HTML5-based LX Platform interface support full remote power monitoring, notifications, and outlet control through a standard web browser. This TAA-compliant PDU is well suited to server rooms and network closets where remote reboot capability reduces maintenance overhead.

Product Description

The PDUMH20NET2LX 1.9kW single-phase switched PDU provides advanced network control and remote power monitoring with the ability to turn on, turn off, reboot, or lock out power to each outlet. By reducing the frequency of on-site visits, these advanced remote capabilities can save money and reduce downtime for IT teams supporting distributed racks. The 1U PDU features eight switched NEMA 5-15/20R outlets with an included cord retention bracket to prevent cables from becoming accidentally disconnected. A 12-foot cord with a NEMA L5-20P plug and 5-20P plug adapter connects the PDU to a compatible AC power source, generator, or protected UPS. The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser, SNMP, telnet, or SSH, supporting 10/100 Mbps auto-sensing Ethernet communication. Optional EnviroSense2 modules, sold separately, add environmental monitoring capabilities. A digital ammeter allows real-time monitoring of total load to keep consumption well below maximum capacity. The single-phase PDU installs in 1U of space in EIA-standard 19-inch racks, and can also be mounted vertically in 0U of rack space or on a wall or under a counter with included brackets and user-supplied screws.

Key Features

• 8 Switched Outlets — Remotely turn on, turn off, reboot, or lock out power to each outlet.
• LX Platform Web Interface — Java-free HTML5-based access via secure browser, SNMP, telnet, or SSH.
• Digital Ammeter — Real-time total load monitoring for the PDU.
• Flexible 1U or 0U Mounting — Installs in 1U rack space or vertically in 0U, plus wall or under-counter mounting.
• 12-Foot Cord with Adapter — L5-20P plug with 5-20P adapter for compatible power sources.
• TAA Compliant — Eligible for GSA Schedule and other federal procurement contracts.

Typical Applications

• Server room and network closet racks
• Distributed IT infrastructure requiring remote control
• Government and federal facility racks

Technical Specifications

Frequently Asked Questions

Can this PDU reboot individual outlets remotely?

Yes, each of the 8 switched outlets can be turned on, turned off, rebooted, or locked out individually through the LX Platform interface.

What mounting options does this PDU support?

It installs in 1U of rack space, or can be mounted vertically in 0U of rack space, on a wall, or under a counter with included brackets.

Is this PDU TAA-compliant?

Yes, it is compliant with the Federal Trade Agreements Act, making it eligible for GSA Schedule and other federal procurement contracts.

What protocols does the LX Platform support?

It supports IPv4, IPv6, HTTP, HTTPS, SMTP, SNMPv1/v2/v3, telnet, SSH, FTP, DHCP, and NTP over 10/100 Mbps Ethernet.

What warranty does Eaton provide on this PDU?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.

Can Creation Networks help with network setup for remote PDU management?

Yes, our team can help plan network access, SNMP configuration, and integration with existing monitoring tools.
