Eaton PDU15NETLX – 1.4kW Switched Mini PDU, LX Platform

Product Overview

The Eaton PDU15NETLX is a 0U switched mini PDU built for small-scale network configurations that need remote outlet control without the footprint of a full-size rack PDU. Equipped with two individually switched NEMA 5-15R outlets and Eaton's Java-free HTML5 LX Platform network interface, this switched PDU lets IT staff turn outlets on, off, or recycle power to unresponsive devices from anywhere on the network. It is a practical fit for network closets and edge racks where only one or two devices need remote power cycling.

Product Description

Many small network installations only need to control power to a handful of devices, and the PDU15NETLX is purpose-built for exactly that scenario. Its two NEMA 5-15R outlets are individually switched, so a technician can remotely turn on, turn off, recycle, or lock out power to a single unresponsive router, switch, or access point without affecting the other connected device. Front-panel LEDs indicate the on/off status of each outlet at a glance, which is useful during rack audits or troubleshooting. The built-in LX Platform is a Java-free, HTML5-based network management interface that provides full remote access for PDU status monitoring and email notifications, so administrators can be alerted automatically if an outlet's status changes unexpectedly. As a 0U design, the PDU15NETLX can be mounted in the cable management area of a rack enclosure without consuming a full rack unit, an important consideration in space-constrained network closets. This mini PDU is well suited for branch offices, small server rooms, and edge network deployments where remote power cycling reduces the need for an on-site truck roll to reboot a stuck device.

Key Features

• Individually Switched Outlets — Two NEMA 5-15R outlets can be turned on, off, or recycled independently to reboot unresponsive equipment remotely.
• Java-Free HTML5 LX Platform — The built-in web interface provides full remote access for PDU status monitoring and email notifications without requiring legacy Java plug-ins.
• Front-Panel Status LEDs — Each outlet's on/off state is visible at a glance for quick visual audits.
• Compact 0U Form Factor — The mini PDU fits into cable management space without consuming a rack unit.
• Remote Power Recycling — Administrators can recycle power to a locked-up device without a site visit, reducing downtime.

Typical Applications

• Network closets
• Server rooms
• Small data center edge racks

Technical Specifications

Frequently Asked Questions

Can the PDU15NETLX be managed without installing software?

Yes, the LX Platform is a Java-free HTML5 web interface accessible from a standard browser, so no client software installation is required.

How many devices can this PDU control?

The unit provides two individually switched outlets, making it suited to controlling one or two devices rather than a full rack of equipment.

Does the unit send alerts if an outlet changes state?

Yes, the LX Platform can send email notifications tied to outlet status changes.

How is the PDU15NETLX installed in a rack?

As a 0U device, it is typically installed in the cable management area of a rack enclosure rather than occupying a dedicated rack unit.

Is this PDU compatible with standard network equipment?

Yes, its NEMA 5-15R outlets accept standard NEMA 5-15P power cords used by routers, switches, and similar network devices.

What warranty applies to this unit?

Eaton backs this unit with its standard manufacturer warranty; contact Creation Networks for the current term and any extended coverage options.
