Eaton OMNIVSINT800 – 230V 800VA Line-Interactive UPS with C13 Outlets

Product Overview

The Eaton OMNIVSINT800 is a 230V, 800VA/475W line-interactive UPS with C13 outlets built for international installations where AV racks, network switches, and control equipment run on 220-240V power. As a 230V line-interactive UPS with C13 outlets, it functions as an international UPS for commercial AV equipment in conference rooms and equipment closets outside North America. Automatic Voltage Regulation and USB-based shutdown make it a practical 800VA UPS with USB shutdown for AV rack deployments protecting entry-level PC systems and network gear.

Product Description

The OMNIVSINT800 is a line-interactive UPS system built to voltage-regulate and surge-protect sensitive electronics on 230V circuits, the standard in most markets outside North America. Internal battery capacity supports entry-level PC systems and small AV control equipment for up to roughly 10 minutes at reduced load, enough to ride out short utility blips or shut down cleanly during longer outages. Automatic Voltage Regulation corrects brownouts as low as 159V back to usable output levels without drawing on battery power, which extends battery life in regions with less stable grid power. The unit provides C13 outlets split between battery-backed and surge-only groups, matching the IEC power connectors standard on international AV and networking equipment, making it a good fit as a C13 outlet UPS for network and AV gear in racks built to IEC specifications rather than NEMA. The included USB port enables unattended system shutdown software so a connected PC or AV processor saves state and powers down safely if an outage runs past the battery's capacity. Tower or wall-mount installation options suit both small equipment closets and open-frame AV racks in conference rooms and huddle spaces.

Key Features

• 230V Line-Interactive Protection — Provides voltage regulation and surge suppression matched to 220-240V international power standards.
• C13 IEC Outlets — Six total C13 receptacles, four battery-backed and two surge-only, matching standard international AV and IT power cords.
• Automatic Voltage Regulation (AVR) — Corrects brownouts down to 159V without switching to battery power, preserving battery life.
• USB Unattended Shutdown — Enables connected systems to save state and shut down safely during extended outages.
• Hot-Swappable VRLA Battery — Allows battery replacement without powering down connected equipment.
• TEL/DSL Surge Protection — Protects connected telecom and data lines from surges alongside AC power protection.

Typical Applications

• International conference rooms running 230V AV racks and control equipment
• Commercial meeting spaces with IEC-standard network and AV equipment
• Small huddle rooms outside North America needing entry-level UPS protection

Technical Specifications

Frequently Asked Questions

Is the OMNIVSINT800 compatible with North American 120V equipment?

No. It is built for 230V nominal input and output and uses C13 IEC outlets, so it is intended for international installations rather than 120V NEMA-based AV racks.

Can this UPS be rack-mounted?

The OMNIVSINT800 is a tower-format unit with wall-mount capability. It is not designed for rack-mount installation; for rack-mount 230V protection, consult Creation Networks for compatible rack UPS options.

How does the USB port integrate with AV control systems?

The USB port supports unattended shutdown software on a connected PC or control processor, allowing it to save its state and power down safely if an outage exceeds battery runtime.

What is the warranty on the OMNIVSINT800?

It carries a 2-year limited warranty, with coverage terms varying by country of purchase.

Can the internal battery be replaced without a technician?

Yes. The VRLA battery is hot-swappable, so it can be replaced by facilities staff without powering down connected equipment.

Does Creation Networks support international AV installations using this UPS?

Yes. Contact Creation Networks for guidance on matching the OMNIVSINT800 to your international AV rack's power and outlet requirements.
