Eaton EMIT05-10 – 208V Metered PDU 16 C13 Outlets

Product Overview

The Eaton EMIT05-10 metered rack PDU is a 208V single-phase unit built for high-density server racks that need many standard C13 outlets rather than a mixed connector layout. With sixteen C13 receptacles and a 5.76 kW capacity, it is well suited to data center and colocation cabinet installations running large numbers of 1U and 2U servers. Integrators handling 16-outlet metered PDU installation across a row of racks will find the EMIT05-10 a consistent, high-outlet-count option within the EMIT platform.

Product Description

The EMIT05-10 is a 1U, 200-240V, 24A metered input rack PDU with sixteen IEC C13 output receptacles, providing one of the highest outlet counts in the EMIT metered PDU family without moving to a mixed connector design. This makes it a strong fit for data center and colocation cabinet deployments populated primarily with standard rack servers, switches, and appliances that use C14 power cords. As a metered input PDU, it reports aggregate input current at the rack so facilities teams can monitor circuit loading and plan capacity across a row of cabinets. The unit's L6-30P twist-lock input plug is rated for the higher current draw associated with sixteen active outlets, and its 1U horizontal form factor keeps the footprint minimal even in cabinets running at high port density. Built-in ethernet and RS-232 connectivity allow load data to be reported to a network monitoring platform, supporting facilities that centralize power visibility across multiple racks. Operating temperature tolerance from 0° to 60°C accommodates less tightly controlled server rooms as well as fully conditioned data center environments. UL listing and TAA compliance support specification in commercial and government space projects. A 3-year limited warranty backs the unit for long-term deployment in production environments.

Key Features

• Sixteen C13 Outlets — Sixteen IEC C13 receptacles support high-density server racks without requiring a second PDU or mixed connector types.
• 208V, 24A Input Capacity — The 200-240V, 24A input delivers up to 5.76 kW, supporting substantially more connected load than 120V metered PDUs.
• L6-30P Twist-Lock Input — A locking NEMA L6-30P plug provides a secure, vibration-resistant connection for higher-current data center circuits.
• Ethernet and RS-232 Monitoring — Network and serial interfaces allow the unit to report input current data to a centralized monitoring platform.
• 1U Rack-Mount Form Factor — The compact 1U chassis preserves rack space in high-density server and colocation cabinet deployments.
• UL Listed and TAA Compliant — UL listing and TAA compliance support procurement in commercial and government space projects.
• 3-Year Limited Warranty — Eaton backs the EMIT05-10 with a 3-year limited warranty for long-term production deployment.

Typical Applications

• data center
• colocation cabinet
• server room
• government space

Technical Specifications

Frequently Asked Questions

How many servers can the EMIT05-10 support?

The unit provides 16 C13 outlets, so it can connect up to 16 devices using standard C14 power cords, subject to the total 24A/5.76kW input rating and each device's individual draw.

What input circuit does this PDU require?

A dedicated 200-240V single-phase circuit rated at 24A or higher, terminated with a NEMA L6-30R receptacle.

Does the EMIT05-10 offer per-outlet metering or switching?

No. It meters total input current only and does not provide per-outlet metering, load shedding, or remote switching.

Can this PDU be monitored remotely over the network?

Yes. It includes an ethernet interface and RS-232 serial port, allowing input current readings to be sent to a network monitoring station or management platform.

Is the EMIT05-10 suitable for a fully populated colocation cabinet?

Yes. Its 16-outlet C13 configuration and 5.76kW capacity make it well suited to high-density colocation cabinet and data center deployments.

Is this PDU TAA compliant?

Yes, Eaton lists the EMIT05-10 as TAA compliant, which is relevant for government space and federal procurement.

What warranty coverage does Eaton provide?

Eaton provides a 3-year limited warranty on the EMIT05-10. Contact Eaton or Creation Networks for full terms and support.
