Eaton EMA114-10 – 24-Outlet 0U Vertical Managed PDU

Product Overview

The Eaton EMA114-10 is a 0U vertical managed rack PDU delivering 24 NEMA 5-20R outlets on a 120V, 16A circuit, built for high-density server and colocation cabinets that need more outlets while staying on standard 120V power. This managed PDU installation is a fit for data center racks, colocation cabinets, and server rooms running dense 1U server counts or a mix of network and compute equipment. Integrators use it where 24-outlet density is needed without moving to a 200-240V input.

Product Description

The EMA114-10 accepts a 120V, 16A input through a NEMA L5-20P twist-lock plug and distributes power across 24 NEMA 5-20R outlets rated to 1.92 kW maximum. The higher outlet count on a single PDU supports dense equipment loads common in colocation cabinet and data center deployments, reducing the number of PDUs, network cards, and monitoring points that need to be managed per rack.

As a managed rack PDU, the EMA114-10 reports load data over RS-232 and includes support for Eaton's eNMC network management card for Ethernet-based remote monitoring, giving data center and colocation operators outlet-level visibility into circuit loading without a site visit. This is particularly relevant in colocation cabinet environments where power headroom is monitored closely as tenants add equipment.

The 0U vertical form factor keeps the PDU out of usable rack unit space, an important factor in dense server rooms and colocation cabinets already populated with compute, storage, and network gear. The L5-20P twist-lock input plug provides a secure connection that resists accidental disconnection in busy, frequently serviced racks.

For integrators standardizing on 120V power distribution at higher densities, the EMA114-10 provides 24-outlet capacity while keeping the same managed PDU monitoring architecture used across Eaton's EMA series, simplifying spares and monitoring configuration across a facility.

Key Features

• 24 NEMA 5-20R Outlets — Supports dense server, storage, and network equipment loads on a single 120V PDU.
• 120V, 16A Input with L5-20P Twist-Lock Plug — Provides a secure connection suited to busy, frequently serviced data center and colocation racks.
• 0U Vertical Mounting — Preserves usable rack unit space in high-density server and colocation cabinets.
• Remote Outlet Monitoring — Reports load over RS-232 with optional eNMC network card support for Ethernet-based monitoring.
• 1.92 kW Capacity — Provides headroom for growing 120V equipment counts in dense cabinets.
• UL Listed, RoHS and TAA Compliant — Meets commercial safety and environmental standards for data center and government procurement.

Typical Applications

• Data center
• Colocation cabinet
• Server room
• Government space

Technical Specifications

Frequently Asked Questions

What circuit does the EMA114-10 require?

It requires a 120V, 16A circuit terminated in a NEMA L5-20 twist-lock receptacle. Confirm this circuit type is available, or plan for an electrician to install one, before ordering.

Is the EMA114-10 a good fit for a colocation cabinet?

Yes. Its 24-outlet count and 0U vertical mounting are designed for dense colocation cabinets and data center racks where rack unit space is limited and outlet density matters.

Does the EMA114-10 support remote monitoring integration?

Yes. It reports load over RS-232 and supports Eaton's eNMC network management card for Ethernet-based integration with data center monitoring and DCIM platforms.

How does the L5-20P input differ from a standard NEMA 5-20 plug?

The L5-20P is a twist-lock connector that locks into a matching receptacle, reducing the risk of accidental disconnection in busy racks compared with a standard straight-blade plug.

What warranty is included with the Eaton EMA114-10?

Eaton provides a 3-year limited warranty. Contact Eaton or Creation Networks for full terms and RMA information.

Can Creation Networks assist with power planning across multiple racks?

Yes. Creation Networks helps integrators and data center operators plan circuit assignments and outlet allocation when deploying multiple EMA114-10 units across a row of cabinets.
