Da-Lite FullVision FC10A108X192 16:9 Parallax 1.0 Fixed Frame Screens (220" Diagonal)

Product Overview

The Da-Lite FullVision is a borderless fixed frame projection screen designed for commercial AV environments where the screen should visually recede when not in use and deliver high-quality projection when active. The FullVision FC10A108X192 provides a 220" diagonal HDTV 16:9 viewing area measuring 108" × 192" with the Parallax 1.0 surface — an ambient light rejecting (ALR) surface for large venues with elevated ambient light. This is the largest FullVision FC10A 16:9 size.

Product Description

The Da-Lite FullVision FC10A108X192 provides a 220" diagonal 16:9 HDTV borderless fixed frame projection screen with the Parallax 1.0 ambient light rejecting surface. The Parallax 1.0 surface is engineered for rooms with significant ambient light, using angular reflectance properties to reject off-axis ambient light while directing projected light toward the primary viewing axis. The 16:9 aspect ratio is native to 1080p, 4K, and UHD projectors. The borderless frame design presents no visible surround. The aluminum frame extends only 1-3/16" from the wall. Screen surface attaches via Velcro to the rear of the frame for field replacement. Standard black backing maintains image contrast. The seamless surface spans the full 220" diagonal without any center seam. Wall mounting uses two screws; ceiling cable suspension is available. For the largest FullVision 16:9 screen with non-ALR surfaces, see FC6H108X192, FC9H108X192, FC11H108X192, FC11C108X192, and FC13H108X192 at creationnetworks.net.

Key Features

• Borderless Frame Design — No visible frame border; the screen blends with the wall when the projector is off.
• Parallax 1.0 ALR Surface — Ambient light rejecting surface maintains image contrast in large venues with significant ambient light at 220".
• Ultra-Low Profile — Only 1-3/16" from wall to screen surface.
• Velcro Surface Attachment — Field surface replacement without removing the frame.
• Lightweight Aluminum Frame — Rigid construction; two-screw wall hanging bracket.
• Ceiling Cable Suspension Option — Alternate installation where wall mounting is not feasible.
• Standard Black Backing — Prevents ambient light transmission; maintains full image contrast.
• Seamless Viewing Surface — No center seam on any model.

Typical Applications

• Large auditoriums and commercial venues with significant ambient light requiring ALR performance at 220" 16:9 format
• Houses of worship and large institutional spaces specifying borderless design with ambient light rejection at maximum size
• Large-format commercial AV installations where both borderless frame and ALR surface are required at 220"
• Venues where window light or architectural lighting makes standard surfaces insufficient at large screen sizes

Technical Specifications

Frequently Asked Questions

Q: What is the Parallax 1.0 surface?

A: Parallax 1.0 is an ambient light rejecting (ALR) surface that uses angular reflectance to reject off-axis ambient light while directing projected light toward the primary viewing axis, maintaining image contrast in rooms with elevated ambient light.

Q: Can the screen surface be replaced without removing the frame?

A: Yes. The surface attaches to the rear of the frame with Velcro, allowing field surface replacement or upgrade without disturbing the frame mounting.

Q: How does FullVision differ from Cinema Contour or UTB Contour?

A: The FullVision is borderless — there is no visible frame around the projection area. The Cinema Contour has a wider, more substantial black frame. The UTB Contour has the thinnest bezel of any framed fixed screen. All three are available at creationnetworks.net.

Q: What is the installation method?

A: The aluminum frame mounts to two screws in the wall. Alternately, the frame can be hung from the ceiling using cables for a suspended installation where wall fastening is not available or desired.
