Crown XLS1502 Two-channel, 525W @ 4Ohm Power Amplifier
Crown XLS1502 – 2-Channel 525W XLS DriveCore 2 Power Amplifier
Product Overview
The Crown XLS1502 is a two-channel, 525-watt-per-channel professional power amplifier from Crown's XLS DriveCore 2 Series, providing mid-range output with DriveCore efficiency, a built-in PFC power supply, and an onboard loudspeaker crossover for biamplification applications. The XLS1502 is suited for conference rooms, houses of worship, auditoriums, and commercial AV installations requiring higher output than the XLS1002 with the same compact and efficient XLS DriveCore 2 platform.
Product Description
The XLS1502 delivers 525 watts per channel into 4 ohms using Crown's DriveCore IC technology. The integrated PFC power supply provides consistent performance across varying AC voltage conditions. The onboard loudspeaker crossover enables biamplification configurations without an external processor. The amplifier supports 2-ohm, 4-ohm, and 8-ohm stereo loads and bridge mono operation. Front-panel LCD and controls allow on-site configuration and signal monitoring.
Key Features
- 525W per channel at 4Ω — Mid-range output for conference room and commercial AV main speaker applications.
- Crown DriveCore technology — Integrated IC for high-efficiency amplification.
- Built-in PFC power supply — Consistent performance across varying AC voltage conditions.
- Onboard loudspeaker crossover — Built-in crossover for biamplification without external processing.
- Front-panel LCD — On-site status display and configuration.
- 2Ω load stability — Stable at demanding low-impedance loads.
- Bridge mono capability — Channels bridgeable for higher single-channel output.
- Comprehensive protection — DC, thermal, and short-circuit protection on both channels.
Typical Applications
- Conference room and boardroom main speaker systems
- House of worship fill and zone speaker amplification
- Auditorium and multi-purpose room sound reinforcement
- Biamplified speaker system applications
- Commercial meeting space foreground audio
- Training room and classroom speaker systems
Technical Specifications
| Specification | Value |
|---|---|
| Channels | 2 |
| Power Output (4Ω stereo) | 525W per channel |
| Power Output (8Ω stereo) | 300W per channel |
| Power Output (bridge mono, 8Ω) | 1050W |
| Minimum Load Impedance | 2Ω stereo / 4Ω bridge |
| PFC Power Supply | Yes |
| Onboard Crossover | Yes |
| DriveCore Technology | Yes |
| SKU | XLS1502 |
| Full specs | See vendor datasheet |
Frequently Asked Questions
- How does the XLS1502 differ from the XLS1002?
- The XLS1502 delivers 525 watts per channel versus 350 watts on the XLS1002, providing additional headroom for larger speaker loads and louder commercial audio applications.
- Does the XLS1502 include full parametric DSP?
- The XLS1502 includes an onboard crossover and signal delay/limiter. For full parametric EQ and advanced DSP, the Crown XTi 2 Series is recommended.
- What is the warranty?
- Crown XLS DriveCore 2 Series amplifiers carry a 3-year limited warranty. Contact Creation Networks for service information.
