Crown XLS 2502 – 2-Channel 775W DriveCore Power Amplifier
Product Overview
The Crown XLS 2502 is the flagship model in Crown's XLS DriveCore 2 series, delivering 775 watts per channel in an ultra-lightweight 10-pound chassis. The XLS 2502 combines maximum DriveCore 2 output power with onboard DSP and Crown's renowned reliability — the ultimate choice for professionals demanding the most from the XLS platform.
Product Description
The Crown XLS 2502 tops the XLS DriveCore 2 lineup with 775 watts per channel into 4 ohms, making it capable of handling the most demanding applications in the series. Remarkably, the XLS 2502 achieves this output in an ultra-compact 10-pound chassis — lighter even than the XLS 2002 — thanks to Crown's advanced DriveCore 2 technology. The onboard DSP includes sweepable high-pass and low-pass filters with crossover mode selection, providing full loudspeaker management integration. For touring professionals, rental companies, and installed sound contractors who require maximum XLS-series output in the lightest possible package, the XLS 2502 is the definitive choice.
Key Features
- 775W Per Channel @ 4Ω: Maximum output in the XLS DriveCore 2 series — the most powerful XLS model.
- DriveCore 2 Technology: Single-chip driver/output integration for industry-leading power-to-weight ratio.
- Onboard DSP: Sweepable HPF, LPF, and crossover mode selection for integrated loudspeaker management.
- Only 10 lbs: The lightest high-power amplifier in the XLS series.
- Class D Efficiency: Exceptional power conversion efficiency for reduced operating costs.
- Balanced XLR Inputs.
- Speakon & Binding Post Outputs.
- 2U Rack Mount.
Typical Applications
- Large PA Systems: High-output sound reinforcement for large venues and events.
- Houses of Worship: High-power church PA with integrated active crossover capability.
- Touring & Rental: Maximum XLS-series power in an ultra-portable package.
- Subwoofer Arrays: Bridged mono operation for high-output subwoofer systems.
Technical Specifications
| Specification | Value |
|---|---|
| Channels | 2 |
| Power Output (per channel @ 4Ω) | 775W |
| Power Output (per channel @ 8Ω) | 480W |
| Bridged Mono @ 8Ω | 1550W |
| DSP | Yes – Built-in (HPF, LPF, Crossover) |
| Amplifier Technology | DriveCore 2 (Class D) |
| Input Connectors | XLR |
| Output Connectors | Speakon, Binding Post |
| Frequency Response | 20Hz – 20kHz (±1dB) |
| THD+N | <0.5% |
| Signal-to-Noise Ratio | >100dB |
| Form Factor | 2U Rack Mount |
| Weight | 10 lbs |
| SKU | NXLS2502-0-US |
| UPC | 691991001161 |
Frequently Asked Questions
- Why is the XLS 2502 lighter than the XLS 2002 despite more power?
- Crown's DriveCore 2 technology continues to improve with each iteration, allowing the XLS 2502 to achieve 775W per channel in a 10-pound chassis versus 13.5 pounds for the XLS 2002. This is a testament to the efficiency and compactness of the DriveCore 2 platform.
- What bridged mono output does the XLS 2502 provide?
- In bridged mono mode, the XLS 2502 delivers approximately 1550W into 8Ω — suitable for large subwoofer systems and high-SPL applications.
- Is the XLS 2502 a good choice for touring?
- Yes. The XLS 2502's extreme power-to-weight ratio makes it ideal for touring applications where weight is a critical concern. Its 10-pound chassis delivers 775W per channel — a combination rarely matched in the professional amplifier market.
- Does the XLS 2502 support network control?
- The XLS 2502 does not include HiQnet or Ethernet networking. For network-controlled amplification, Crown's XTi 2 and I-Tech HD series include HiQnet connectivity. The XLS 2502's onboard DSP is accessible via front-panel controls.
- What warranty covers the XLS 2502?
- The Crown XLS 2502 carries Crown's 3-year limited warranty for professional audio amplifiers.
