Crown XLS 2002 – 2-Channel 650W DriveCore Power Amplifier
Product Overview
The Crown XLS 2002 is a 2-channel 650W DriveCore 2 power amplifier stepping up to 13.5 pounds with increased output power for medium-to-large professional audio applications. Part of Crown's acclaimed XLS DriveCore 2 series, the XLS 2002 combines efficient Class D performance with onboard DSP for a complete amplification and signal processing solution.
Product Description
The Crown XLS 2002 delivers 650 watts per channel into 4 ohms, handling medium-to-large PA systems, installed sound applications, and active subwoofer configurations with reliability and efficiency. Crown's DriveCore 2 technology keeps the chassis remarkably lightweight at 13.5 pounds — a fraction of the weight of comparable traditional amplifiers. The onboard DSP provides sweepable high-pass and low-pass filtering with crossover mode selection, reducing the need for external signal processing equipment in most applications.
Key Features
- 650W Per Channel @ 4Ω: High output for medium-to-large PA and subwoofer systems.
- DriveCore 2 Technology: Crown's patented lightweight Class D amplifier platform.
- Onboard DSP: Sweepable HPF, LPF, and crossover mode selection.
- 13.5 lbs: Lightweight chassis for easy transport and rack installation.
- High-Efficiency Class D: Lower power consumption and heat output versus traditional Class AB designs.
- XLR Inputs: Balanced professional inputs.
- Speakon & Binding Post Outputs.
- 2U Rack Mount.
Typical Applications
- Medium-to-Large PA Systems: Venues requiring clean, high-output amplification with integrated DSP.
- Houses of Worship: Church PA systems with active crossover needs.
- Subwoofer Amplification: Bridged mono operation for high-output subwoofer systems.
- DJ & Event Production: Portable high-power amplification with lightweight advantage.
Technical Specifications
| Specification | Value |
|---|---|
| Channels | 2 |
| Power Output (per channel @ 4Ω) | 650W |
| Power Output (per channel @ 8Ω) | 400W |
| Bridged Mono @ 8Ω | 1300W |
| DSP | Yes – Built-in (HPF, LPF, Crossover) |
| Amplifier Technology | DriveCore 2 (Class D) |
| Input Connectors | XLR |
| Output Connectors | Speakon, Binding Post |
| Frequency Response | 20Hz – 20kHz (±1dB) |
| THD+N | <0.5% |
| Signal-to-Noise Ratio | >100dB |
| Form Factor | 2U Rack Mount |
| Weight | 13.5 lbs |
| SKU | NXLS2002-0-US |
| UPC | 691991001086 |
Frequently Asked Questions
- What is the advantage of DriveCore 2 over traditional amplifier designs?
- DriveCore 2 integrates the driver and output stage into a single chip, dramatically reducing component count, chassis weight, and power consumption. The result is an amplifier that weighs a fraction of its Class AB equivalent while delivering comparable or better audio performance.
- How does the XLS 2002 compare to the XLS 2502?
- The XLS 2502 delivers 775W per channel versus 650W for the XLS 2002. The XLS 2502 is the better choice for applications requiring maximum output from the XLS DriveCore 2 platform. Both share the same technology and feature set.
- What bridged mono output does the XLS 2002 provide?
- In bridged mono mode, the XLS 2002 delivers approximately 1300W into 8Ω — suitable for high-output subwoofer applications.
- Can the XLS 2002 drive 2Ω loads?
- The XLS 2002 is rated for 4Ω minimum per channel in stereo mode. Please consult the user manual for bridged mono impedance specifications and safe operating parameters.
- What warranty applies?
- The Crown XLS 2002 carries Crown's 3-year limited warranty for professional audio amplifiers.
