Crown XLS 1002 – 2-Channel 350W DriveCore Power Amplifier
Product Overview
The Crown XLS 1002 is a 2-channel 350W DriveCore 2 power amplifier combining Crown's lightweight DriveCore technology with built-in DSP and crossover for professional audio systems. The XLS 1002 is the entry-level model in Crown's XLS DriveCore 2 series, delivering Crown quality in a compact, efficient package.
Product Description
The Crown XLS 1002 uses Crown's proprietary DriveCore 2 amplifier technology, which integrates the driver stage and output stage onto a single chip, resulting in significantly reduced weight, improved efficiency, and enhanced reliability. At just 11 pounds, the XLS 1002 is one of the lightest professional amplifiers available at its power level. It includes an onboard 2-channel DSP with sweepable high-pass filter, optional low-pass filter, and selectable crossover modes — making it a versatile all-in-one amplifier and processor solution for professional and installed sound applications.
Key Features
- 350W Per Channel @ 4Ω: Reliable output power for small-to-medium PA and installed sound systems.
- DriveCore 2 Technology: Crown's innovative single-chip driver/output integration for ultra-lightweight, efficient performance.
- Onboard DSP: Built-in 2-channel DSP with sweepable high-pass filter, low-pass filter, and crossover mode selection.
- Ultralight Design: Only 11 pounds — significantly lighter than traditional amplifiers at this power level.
- Class D Efficiency: High-efficiency Class D amplifier topology reduces power consumption and heat generation.
- Balanced XLR Inputs: Professional balanced inputs with excellent noise rejection.
- Speakon & Binding Post Outputs: Dual output connector options for flexible system integration.
- 2U Rack Mount: Standard professional rack format.
Typical Applications
- Small-to-Medium PA Systems: Portable and installed PA systems requiring lightweight, efficient amplification.
- Houses of Worship: Church sound systems benefiting from the XLS 1002's built-in DSP crossover capabilities.
- DJ & Entertainment: Lightweight amplification for mobile DJ systems and portable event sound.
- Installed Sound: Background music, paging, and small venue installed sound with integrated DSP processing.
Technical Specifications
| Specification | Value |
|---|---|
| Channels | 2 |
| Power Output (per channel @ 4Ω) | 350W |
| Power Output (per channel @ 8Ω) | 215W |
| Bridged Mono @ 8Ω | 700W |
| DSP | Yes – Built-in (HPF, LPF, Crossover) |
| Amplifier Technology | DriveCore 2 (Class D) |
| Input Connectors | XLR |
| Output Connectors | Speakon, Binding Post |
| Frequency Response | 20Hz – 20kHz (±1dB) |
| THD+N | <0.5% |
| Signal-to-Noise Ratio | >100dB |
| Form Factor | 2U Rack Mount |
| Weight | 11 lbs |
| SKU | NXLS1002-0-US |
| UPC | 691991000935 |
Frequently Asked Questions
- What is DriveCore 2 technology?
- DriveCore 2 is Crown's proprietary amplifier technology that integrates the driver and output stages onto a single chip. This integration dramatically reduces component count, weight, and power consumption compared to traditional Class AB designs, while maintaining Crown's standard for audio quality and reliability.
- Does the XLS 1002 include a crossover?
- Yes. The XLS 1002 includes an onboard DSP section with a sweepable high-pass filter, an optional low-pass filter, and crossover mode selection — allowing it to function as both an amplifier and active crossover without requiring additional external processing equipment.
- How does the XLS 1002 compare to the XLS 1502?
- The XLS 1502 delivers 525W per channel versus 350W for the XLS 1002. The XLS 1502 is suitable for slightly larger systems requiring more headroom. Both feature the same DriveCore 2 technology and onboard DSP.
- Can the XLS 1002 operate in bridged mono mode?
- Yes. The XLS 1002 supports bridged mono operation, delivering approximately 700W into 8Ω for applications requiring higher single-channel output.
- What warranty does the XLS 1002 carry?
- The Crown XLS 1002 is backed by Crown's 3-year limited warranty for professional audio amplifiers.
