Crown XLi 3500 – 2-Channel 1350W Power Amplifier
Product Overview
The Crown XLi 3500 is the flagship model in Crown's XLi series, delivering 1350 watts per channel for high-power professional audio applications. Designed for large PA systems, subwoofer amplification, and demanding installed sound environments, the XLi 3500 provides maximum output from the XLi platform with Crown's renowned reliability.
Product Description
When maximum power is required from the XLi series, the Crown XLi 3500 is the answer. Delivering 1350 watts per channel into 4 ohms, the XLi 3500 is capable of driving large main PA systems, high-output subwoofer arrays, and demanding installed sound applications where lesser amplifiers would fall short. Its robust power supply and efficient thermal management ensure consistent performance even under sustained high-output conditions. The XLi 3500 combines Crown's proven reliability with the straightforward controls and dual-input/dual-output connectivity that characterizes the XLi series.
Key Features
- 1350W Per Channel @ 4Ω: Maximum output power in the XLi series for large PA, subwoofer, and high-SPL applications.
- 2-Channel Design: Stereo, dual-mono, and bridged mono operation for maximum deployment flexibility.
- Clip Limiting: Speaker-protective clip limiting for high-drive-level protection.
- Variable Input Sensitivity: Accommodates a wide range of source levels.
- Temperature-Controlled Fan Cooling: Efficient cooling for sustained high-power operation.
- XLR & 1/4" TRS Inputs: Balanced and unbalanced input compatibility.
- Speakon & Binding Post Outputs: Dual output connector types.
- 2U Rack Mount: Standard professional rack format.
Typical Applications
- Large Venues: Main PA amplification for large clubs, theaters, and auditoriums.
- Houses of Worship: High-power church PA systems requiring maximum headroom for large congregations.
- Subwoofer Arrays: Bridged mono operation delivers over 2700W for powerful subwoofer systems.
- Touring & Rental: High-power portable and touring systems where maximum XLi output is required.
Technical Specifications
| Specification | Value |
|---|---|
| Channels | 2 |
| Power Output (per channel @ 4Ω) | 1350W |
| Power Output (per channel @ 8Ω) | 800W |
| Bridged Mono @ 8Ω | 2700W |
| Input Connectors | XLR, 1/4" TRS |
| Output Connectors | Speakon, Binding Post |
| Frequency Response | 20Hz – 20kHz (±1dB) |
| THD+N | <0.5% |
| Signal-to-Noise Ratio | >100dB |
| Form Factor | 2U Rack Mount |
| Weight | 40 lbs |
| SKU | NXLI3500-0-US |
| UPC | 871015006925 |
Frequently Asked Questions
- What power does the XLi 3500 deliver in bridged mono mode?
- In bridged mono mode, the XLi 3500 delivers approximately 2700W into 8Ω — making it a formidable subwoofer amplifier for larger systems. Always use an 8Ω minimum load in bridged mono mode.
- Is the XLi 3500 suitable for touring use?
- Yes. The XLi 3500 is a capable touring amplifier for applications where XLi-tier performance is sufficient. For the highest-output touring applications with DSP and network control, Crown's XTi 2 and I-Tech HD series offer additional capabilities.
- How does the XLi 3500 compare to the XTi series?
- The XTi series amplifiers include onboard DSP for active loudspeaker management, which the XLi series lacks. The XLi 3500 is a cost-effective choice for applications where external DSP is already in the signal chain. The XTi 6002, for example, provides 2100W per channel with full DSP.
- What is the minimum impedance for stereo operation?
- The XLi 3500 is rated for 4Ω minimum per channel in stereo mode. In bridged mono, the minimum load is 8Ω. Operating below these specifications risks damage to the amplifier.
- What warranty does the XLi 3500 carry?
- The Crown XLi 3500 is covered by Crown's 3-year limited warranty for professional audio amplifiers.
