Crown I-Tech IT12000HD – 2-Channel 4500W DSP Power Amplifier
Product Overview
The Crown I-Tech IT12000HD is a 2-channel professional power amplifier delivering 4500 watts per channel, purpose-built for the highest-demand touring and large-scale installed sound applications. With onboard DSP and HiQnet networking, the IT12000HD provides unmatched power, precision, and control in a compact 2U rack enclosure.
Product Description
The Crown IT12000HD represents the pinnacle of two-channel amplifier design, combining extraordinary output power with Crown's legendary signal integrity and reliability. The integrated DSP engine handles all loudspeaker management tasks — including crossover, parametric EQ, time alignment, and multi-mode limiting — providing a complete amplifier-processor solution. Its Harman HiQnet network interface enables real-time remote monitoring and control, allowing system technicians to manage large amplifier arrays from a central control station. Whether driving subwoofer arrays at a major music festival or powering line arrays in a large convention center, the IT12000HD delivers the consistent, reliable performance professionals depend on.
Key Features
- 2-Channel High Power: Delivers 4500W per channel into 4Ω — ideal for driving demanding subwoofer and full-range cabinets.
- Onboard DSP: Full-featured digital signal processing with parametric EQ, crossover, delay, and Crown's BandPass Limiter for comprehensive speaker management and protection.
- HiQnet Networking: Ethernet-based HiQnet connectivity for centralized system control, monitoring, and firmware updates via Crown System Architect software.
- PFC Switching Power Supply: Power Factor Corrected supply provides stable performance across international AC mains voltages, essential for global touring.
- Efficient 2U Form Factor: Massive output in a compact 2U chassis reduces rack space requirements and system weight.
- Comprehensive Speaker Protection: Multi-mode limiting, thermal protection, and DC fault detection protect loudspeaker investments in all operating conditions.
- Balanced XLR Inputs: Professional balanced XLR inputs provide excellent common-mode noise rejection for clean signal transfer in complex system environments.
Typical Applications
- House of Worship: Power high-output line array and subwoofer systems with integrated DSP control, reducing equipment requirements and simplifying system management.
- Touring: The IT12000HD is a touring industry standard, trusted by major production companies worldwide for its power density, reliability, and HiQnet control compatibility.
- Concert Venues: Fixed installations in large concert halls and music venues benefit from the amplifier's long-term reliability and centralized network control.
- Stadiums & Arenas: Large distributed stadium PA systems leverage the IT12000HD's high output and network control for consistent coverage across massive venue spaces.
Technical Specifications
| Specification | Value |
|---|---|
| Channels | 2 |
| Power Output (per channel @ 4Ω) | 4500W |
| Power Output (per channel @ 8Ω) | 2800W |
| DSP | Yes – Onboard |
| Networking | HiQnet (Ethernet) |
| Input Connectors | XLR |
| Frequency Response | 20Hz – 20kHz (±0.5dB) |
| THD+N | <0.5% |
| Signal-to-Noise Ratio | >100dB |
| Form Factor | 2U Rack Mount |
| SKU | IT12000HD-U-USFX |
| UPC | 691991008535 |
Frequently Asked Questions
- How does the IT12000HD compare to the IT9000HD?
- The IT12000HD delivers 4500W per channel versus 3500W per channel for the IT9000HD, making it the preferred choice for the highest-demand applications. Both share the same DSP and HiQnet platform. The IT12000HD is typically chosen for subwoofer arrays and full-range high-SPL applications, while the IT9000HD suits slightly smaller systems.
- Is the IT12000HD compatible with Crown's V-Rack systems?
- Yes. The IT12000HD is the amplifier of choice for the VRACK-12000HD system, which packages three IT12000HD amplifiers in a pre-wired, ready-to-deploy road rack. The VRACK solution simplifies setup and ensures all amplifiers are optimally integrated.
- What DSP preset libraries are available?
- Crown and Harman provide extensive loudspeaker preset libraries for use with System Architect software. Presets are available for most JBL Professional and other major loudspeaker brands, enabling fast system setup without custom DSP configuration.
- Does the IT12000HD support bridged mono operation?
- Yes. The IT12000HD can be configured in bridged mono mode for maximum single-channel output, suitable for driving very large subwoofer systems. Ensure that connected loudspeakers are rated for bridged mono operation before use.
- What is the warranty coverage?
- Crown professional amplifiers carry a 3-year limited warranty. Crown maintains a global network of authorized service centers to ensure fast turnaround for any service needs.
