Crown DCI2X1250 – 2-Channel 1250W DriveCore Install Analog Amplifier

Product Overview

The Crown DCI2X1250 is a 2-channel, 1250W per channel DriveCore Install analog power amplifier engineered for high-power installed sound applications. Delivering massive output in a rack-efficient form factor, it supports 70V/100V distributed audio and integrates with Harman's HiQnet networking protocol for system-wide monitoring and control. Built on Crown's proven DriveCore technology, the DCI2X1250 provides exceptional audio performance with outstanding reliability for permanent installations. It is the solution of choice when high-power amplification is required for large commercial and institutional venues.

Product Description

The Crown DCI2X1250 provides 1250 watts per channel across two independent output channels, making it one of the most powerful options in the DCi installed sound amplifier series. DriveCore technology integrates the driver and output stage onto a single IC, delivering superior efficiency, lower heat generation, and exceptional audio fidelity compared to conventional amplifier designs. The amplifier's 70V and 100V transformer outputs enable it to drive large distributed loudspeaker systems across extended cable runs without significant signal loss. HiQnet networking allows the DCI2X1250 to participate in comprehensive Harman system control environments, supporting remote monitoring, preset recall, and real-time parameter adjustment from a central control point. Onboard DSP provides parametric EQ, alignment delay, crossover, and limiting functions to optimize system performance without requiring external processing equipment. The robust 2U rack-mount chassis is built for the demands of permanent installation in venues such as arenas, theaters, and large houses of worship. Balanced XLR analog inputs accept standard professional audio levels. Energy-efficient operation minimizes operational costs in high-use commercial environments. Universal AC input accommodates worldwide power standards. Crown's world-class engineering and support network ensure long-term reliability in mission-critical applications.

Key Features

• DriveCore Technology: Harman's patented single-IC driver/output stage delivers superior efficiency, lower THD, and enhanced reliability.
• 2-Channel High-Power Output: Two independent channels each rated at 1250W for high-SPL installed sound applications.
• 70V/100V Distributed Audio: Transformer outputs support constant-voltage distribution for large commercial speaker systems.
• HiQnet Networking: Integration with Harman's HiQnet protocol enables remote monitoring, control, and preset management.
• Integrated DSP: Built-in parametric EQ, delay, crossover, and limiting functions reduce external processing requirements.
• 2U Rack-Mount Chassis: Rugged, space-efficient design for standard 19-inch equipment racks.
• Balanced XLR Analog Inputs: Professional-grade input connectors for reliable signal connection.
• High-Efficiency Operation: Advanced Class D topology minimizes heat output and power consumption.
• Universal AC Input: Worldwide voltage compatibility for flexible international deployment.
• Mission-Critical Reliability: Crown engineering and quality standards designed for permanent high-uptime installations.

Typical Applications

• Large Venues: Drive high-power speaker arrays in arenas, convention centers, and performing arts facilities.
• House of Worship: Power main PA systems in large sanctuaries requiring high output and 70V zone coverage.
• Retail & Commercial: Serve high-power background music and paging systems in large commercial spaces.
• Multi-Zone Installations: Provide high-output amplification for two independently driven zones in complex installed audio systems.

Technical Specifications

Frequently Asked Questions

How much power does the DCI2X1250 deliver per channel?

Each channel delivers up to 1250 watts, providing the high SPL output required for large venues, main PA systems, and high-power commercial installations.

Does the DCI2X1250 support 70V and 100V distributed audio?

Yes. Onboard transformer outputs support both 70V and 100V constant-voltage distribution for driving large commercial loudspeaker systems over extended cable runs.

What DSP functions are built into the DCI2X1250?

The integrated DSP includes parametric EQ, alignment delay, crossover filtering, and dynamic limiting, providing complete signal processing within the amplifier for simplified system design.

How does HiQnet networking work with the DCI2X1250?

HiQnet allows the DCI2X1250 to be monitored and controlled via Harman's system management software, enabling remote preset recall, real-time parameter adjustment, and fault monitoring from a central control station.

How much rack space does the DCI2X1250 require?

The DCI2X1250 occupies 2U (3.5 inches) of space in a standard 19-inch equipment rack.
