Crestron USB-SW-400 – 4-Port USB-C Data Switcher
Product Overview
The Crestron USB-SW-400 is a 4-port USB-C data switcher that allows up to four host computers to share a single set of USB peripherals. It is designed for conference rooms, collaboration spaces, and workstations where multiple users or workstations need access to shared input devices, storage, or other USB equipment without manually swapping cables.
Product Description
The USB-SW-400 routes USB 3.1 Gen 1 data between any one of four USB-C host ports and a shared bank of USB-A peripheral ports. Switching is controlled via a button on the unit or remotely via RS-232 serial command, allowing integration with room automation systems. The device does not pass power — it is a data switcher, not a KVM with display switching. It installs easily on a desk or conference table surface with the included mounting hardware.
Key Features
- 4 USB-C host ports — share peripherals among up to four computers
- USB 3.1 Gen 1 (5 Gbps) data transfer rate
- Manual front-panel button switching and RS-232 serial control
- Compatible with USB-A peripheral hubs and devices via included USB-C to USB-A adapter cables
- Compact desktop form factor with flush-mount hardware included
- Data switching only — does not pass display signals or charge devices
Typical Applications
- Conference room shared peripheral switching (keyboard, mouse, storage)
- BYOD meeting rooms where multiple laptop users share USB devices
- Huddle space workstations with shared USB-connected peripherals
- AV rack installations requiring RS-232 controlled USB switching
- Collaborative workspaces with shared USB storage or input devices
Technical Specifications
- Model: USB-SW-400
- SKU: USB-SW-400
- Host Ports: 4 x USB-C (USB 3.1 Gen 1)
- Peripheral Ports: USB-A via included adapter cables
- Data Rate: USB 3.1 Gen 1 (5 Gbps)
- Control: Front-panel button, RS-232 serial
- Power: USB bus-powered from host
- Weight: 1.4 lb (0.64 kg)
- Mounting: Desktop, optional flush mount
- Compliance: FCC Part 15 Class B, CE, RoHS
Frequently Asked Questions
Q: Does the USB-SW-400 also switch display/video signals?
A: No. The USB-SW-400 is a USB data switcher only. It switches USB data between host computers and shared peripherals but does not route video, audio, or display signals. For display switching, a separate HDMI or DisplayPort switcher is required.
Q: Can the USB-SW-400 be controlled by a Crestron control processor?
A: Yes. The USB-SW-400 supports RS-232 serial control, allowing it to be integrated with a Crestron 4-Series or other control system to automate peripheral switching as part of a room control sequence.
Q: Does the USB-SW-400 charge connected devices through the USB-C ports?
A: No. The USB-SW-400 passes data only and does not deliver power delivery (PD) charging to connected hosts or peripherals. It is a data switcher, not a USB-C charging hub.
