Crestron TSW-770R-B – 7.0 in. Wall Mount Touch Screen, Black

Product Overview

The Crestron TSW-770R-B is a 7 in. wall mount touch screen for Crestron Home OS residential deployments. It runs the Crestron Home app natively on a 1024 x 600 display and controls lighting, shading, climate, audio/video, and security systems throughout the home. The compact 7 in. form factor fits a standard single-gang or 2-gang wall box and is well-suited for bedrooms, hallways, and secondary control locations in a whole-home Crestron system.

Product Description

The TSW-770R-B shares the same Android-based platform as the larger TSW-1070R-B, providing a consistent Crestron Home experience across all room panels in a residence. Gigabit Ethernet with PoE+ delivers network connectivity and power from a single cable. Wi-Fi 6E allows flexible positioning where wired Ethernet is not accessible. Rava SIP Intercom enables two-way voice communication with door stations and other Rava-capable devices. A proximity sensor wakes the display when someone approaches.

Key Features

• 7 in. (177 mm) IPS display, 1024 x 600 WSVGA at up to 400 nits
• Native Crestron Home OS app for residential whole-home control
• Rava SIP Intercom with far-field microphone and full-duplex speakers
• Gigabit Ethernet with PoE+ (IEEE 802.3at) — single-cable installation
• Wi-Fi 6E (802.11ax, 2.4/5/6 GHz)
• Proximity sensor for automatic wake-on-approach
• XiO Cloud remote provisioning and management
• Single-gang or 2-gang wall box mount, Black finish

Typical Applications

• Secondary room control panels in bedrooms and hallways
• Whole-home Crestron Home OS deployments requiring multiple screen sizes
• MDU in-unit control panels for AV, lighting, shading, and HVAC
• Residential intercom stations via Rava SIP
• Compact control panels in smaller rooms and utility spaces

Technical Specifications

• Model: TSW-770R-B
• SKU: TSW-770R-B
• Display: 7 in. (177 mm) IPS, 1024 x 600 WSVGA, up to 400 nits
• Touch: Projected capacitive, 5-point multitouch
• Network: 1000 Mbps Ethernet, PoE+ (IEEE 802.3at Type 2)
• Wi-Fi: 802.11a/b/g/n/ac/ax Wi-Fi 6E (2.4, 5, 6 GHz)
• Bluetooth: BLE, BT5.2
• Weight: 0.88 lb (400 g)
• Mounting: Single-gang or 2-gang electrical wall box
• Finish: Black
• Operating Temperature: 32–104°F (0–40°C)
• Compliance: FCC Part 15 Class B, IC Class B, CE, UL/Intertek Listed

Frequently Asked Questions

Q: What is the difference between the TSW-770R-B and the TSW-1070R-B?
A: The TSW-770R-B has a 7 in. display (1024 x 600); the TSW-1070R-B has a 10.1 in. display (1280 x 800). Both run Crestron Home OS and have the same connectivity and intercom features. The 7 in. model is typically used for secondary locations; the 10.1 in. model for primary control points.

Q: Does the TSW-770R-B require PoE+ or will standard PoE work?
A: PoE+ (IEEE 802.3at Type 2) is required. Standard PoE (IEEE 802.3af) does not provide sufficient power. Verify your switch or injector supports 802.3at before installation.

Q: Can the TSW-770R-B operate on Wi-Fi without a wired Ethernet connection?
A: Yes. It supports Wi-Fi 6E for wireless operation, but a separate 12V DC power supply is required when Ethernet PoE+ is not used. Wired PoE+ is recommended for production installations.
