Crestron TSS-880-B – 8.1 in. Room Scheduling Touch Screen, Black

Product Overview

The Crestron TSS-880-B is an 8.1 in. room scheduling touch screen that mounts outside meeting rooms to display real-time availability and enable instant booking. It integrates with Microsoft Exchange/Office 365, Google Calendar/G Suite, CollegeNET 25Live, and Ad Astra, making it suitable for enterprise, education, and government deployments. The black finish suits contemporary corporate and institutional interiors.

Product Description

The TSS-880-B features a 1280x800 display at 350-400 nits with projected capacitive 5-point multitouch and an ultra-slim 0.50 in. (13 mm) depth for flush wall installation. It is PoE+-powered via a single CAT cable with no external power supply required. Wi-Fi 6E (802.11ax) with WPA/WPA2/WPA3 Enterprise support provides enterprise-grade wireless connectivity. A Crestron Bluetooth beacon supports room occupancy detection. XiO Cloud enables centralized management across large-scale deployments.

Key Features

• 8.1 in. TFT LCD, 1280x800 WXGA, 16:10, 350-400 nits, 1000:1 contrast, 24-bit color
• Projected capacitive 5-point multitouch; USB Type-C host port
• Ultra-slim 0.50 in. (13 mm) depth for flush wall mount installation
• PoE+ (IEEE 802.3at) single-cable power; no separate power supply required
• Wi-Fi 6E 802.11a/b/g/n/ac/ax 2.4/5/6 GHz 2x2 MIMO; WPA/WPA2/WPA3 Enterprise
• Crestron Bluetooth beacon for occupancy detection
• Scheduling integrations: Microsoft Exchange/365, Google Calendar/G Suite, CollegeNET 25Live, Ad Astra
• Certifications: FCC Part 15 Class B, IC Class B, CE, UL Listed (Intertek)

Typical Applications

• Enterprise conference room scheduling display adjacent to meeting room entrance
• University classroom and collaboration space booking panel
• Government building conference room availability display
• Healthcare facility meeting room management system
• Large campus deployment with XiO Cloud centralized management

Technical Specifications

• Model: TSS-880-B
• Weight: 0.91 lb (415 g)
• Dimensions (H x W x D): 4.87 in. x 7.93 in. x 0.50 in. (124 mm x 201 mm x 13 mm)
• Display Size: 8.1 in. (204 mm) diagonal
• Display Resolution: 1280 x 800 (WXGA, 16:10)
• Brightness: 350-400 nits; 1000:1 contrast; 24-bit color
• Touch: Projected capacitive, 5-point multitouch
• Power: PoE+ IEEE 802.3at Type 2; 30 W (w/o LLDP); 15.4 W from 802.3af; 44 BTU/hr
• Network: 1000 Mbps PoE+ RJ-45; TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP, 802.1X, SNMP, IPv4/IPv6
• Wireless: Wi-Fi 6E 802.11a/b/g/n/ac/ax 2.4/5/6 GHz 2x2 MIMO; WPA/WPA2/WPA3 Enterprise
• Bluetooth: Crestron Bluetooth beacon (occupancy)
• USB: (1) USB Type-C, USB 2.0 host
• Memory: 8 GB LPDDR4 RAM; 40 GB eMMC pSLC; 1,000 MB max project size
• Scheduling: Microsoft Exchange/365, Google Calendar/G Suite, CollegeNET 25Live, Ad Astra
• Operating Temperature: 32 to 104°F (0 to 40°C)
• Certifications: FCC Part 15 Class B, IC Class B, CE, UL Listed (Intertek)

Frequently Asked Questions

Q: Does the TSS-880-B require a Crestron processor for room scheduling?
A: No. The TSS-880-B connects directly to the network and communicates with Exchange, Google Calendar, and other supported platforms independently. A Crestron processor is not required for room scheduling functionality.

Q: What is the difference between the TSS-880-B and the TSS-1080-B?
A: The primary difference is screen size — 8.1 in. (TSS-880-B) versus 10.1 in. (TSS-1080-B). Both support the same scheduling integrations, Wi-Fi 6E, and PoE+ power. The TSS-880-B also has a thinner depth at 0.50 in. versus the TSS-1080-B at 1.18 in.

Q: Can the TSS-880-B detect room occupancy automatically?
A: The TSS-880-B includes a Crestron Bluetooth beacon that can communicate with compatible Crestron occupancy sensors for automated room release when a booked room goes unused.
