Crestron MC4-I – 4-Series Control System, International

Product Overview

The Crestron MC4-I is a compact 4-Series control system designed for international commercial and residential deployments. It functions as a mid-range automation controller supporting Cresnet, infiNET EX wireless, RS-232, IR, relays, and Versiport I/O. PoE-powered and compatible with 100/1000 Mbps networks, it is an efficient choice for integrators deploying Crestron automation outside the United States where international regulatory certifications are required.

Product Description

The MC4-I shares the same compact form factor as the MC4-R, fitting into structured wiring enclosures, DIN rail mounting kits, or standalone surface installation. Its infiNET EX 2.4 GHz wireless module communicates with keypads, sensors, and shades within a 50 ft range. Four IR outputs support legacy AV device control, while two relays and two Versiport I/O ports extend control to motorized equipment and analog sensors. BACnet/IP support allows integration with building management systems in light commercial applications.

Key Features

• 4-Series multicore control processor for international deployments
• PoE-powered (IEEE 802.3at Type 1 / 802.3af Class 0, 12.95 W max); 7 W typical consumption
• Cresnet server mode for wired peripheral distribution
• infiNET EX 2-way 2.4 GHz wireless (IEEE 802.15.4) up to 50 ft range
• 1x RS-232 (up to 115.2k baud), 4x IR outputs, 2x relays, 2x Versiports
• 100/1000 Mbps Ethernet with SSL, TLS, SSH, SFTP, FIPS 140-2, IPv4/IPv6, BACnet/IP
• USB 2.0 Type-A host port (up to 1 TB mass storage)
• Certifications: CE, IC, FCC Part 15 Class B

Typical Applications

• International commercial room control deployments requiring CE certification
• Hospitality suite automation for hotels outside North America
• Light commercial building control with BACnet/IP integration
• Residential automation controller for international markets
• Multi-room infiNET EX wireless device management in retrofit installations

Technical Specifications

• Model: MC4-I
• Weight: 1.0 lb (454 g)
• Dimensions (H x W x D): 1.07 in. x 10.15 in. x 5.11 in. (27 mm x 258 mm x 130 mm)
• Power: PoE IEEE 802.3at Type 1 / 802.3af Class 0 (12.95 W max); 7 W typical; 24 BTU/hr
• Memory: 1 GB SDRAM; 8 GB Flash; microSD up to 32 GB
• Ethernet: 100/1000 Mbps; TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP, FIPS 140-2, IPv4/IPv6, 802.1X, BACnet/IP
• Wireless: infiNET EX 2-way 2.4 GHz ISM 802.15.4, 50 ft range
• Cresnet: Server mode; 2.5 W available
• Serial/IR/I/O: 1x RS-232 (115.2k baud); 4x IR outputs (1.2 MHz max); 2x relays (1A, 30 VAC/VDC); 2x Versiports
• USB: USB 2.0 Type-A host
• Operating Temperature: 41 to 113°F (5 to 45°C)
• Certifications: CE, IC, FCC Part 15 Class B

Frequently Asked Questions

Q: What makes the MC4-I different from the MC4-R?
A: The MC4-I is configured for commercial and international deployments with CE regulatory certification and Crestron's standard commercial control platform. The MC4-R runs Crestron Home OS and is designed for residential automation dealers.

Q: Does the MC4-I support Crestron Home OS?
A: No. The MC4-I runs the standard 4-Series commercial Crestron control platform, programmed via SIMPL or Crestron Studio. For Crestron Home OS deployments, the MC4-R is the appropriate model.

Q: Can the MC4-I be powered without a PoE switch?
A: A PoE injector (802.3at or 802.3af) can be used if a PoE-capable switch is not available. No separate AC power supply is required.
