Crestron HZ2-SWEX-W – In-Wall Wireless Switch, White, Custom Engraved

Product Overview

The Crestron HZ2-SWEX-W is a single-gang in-wall on/off switch with infiNET EX wireless communication, White finish, and customer-specified button engraving. It controls 120 VAC non-dimming loads and communicates over the infiNET EX 2.4 GHz mesh network without requiring a dedicated low-voltage wire run to each device. The White finish is the most common color choice for commercial interiors, and the custom engraving option allows integrators to label buttons to match the specific lighting zone or function in each room.

Product Description

The HZ2-SWEX-W is part of the Crestron Horizon 2 series of in-wall lighting control hardware. It is functionally identical to the HZ2-SWEX-A but ships in White with custom engraving — meaning the button text is specified by the customer or integrator at order time rather than using a standard factory label.

Custom engraving is particularly useful in commercial deployments where room-specific labeling (e.g., "Overhead," "Perimeter," "Exit") improves usability for end users who interact with the switch without formal AV training. infiNET EX mesh handles wireless routing automatically, and AES-128 encryption secures the control link. An infiNET EX gateway is required on the network.

Key Features

• Non-dimming on/off control for 120 VAC loads
• infiNET EX 2.4 GHz wireless mesh communication
• AES-128 encrypted wireless link
• Single-gang decora form factor
• White finish — standard for most commercial interiors
• Custom engraving: button text specified by customer
• Requires infiNET EX gateway for system integration
• Part of the Crestron Horizon 2 lighting control ecosystem

Typical Applications

• Conference rooms and training rooms requiring zone-labeled switches
• Corporate offices with white decora trim standards
• University classrooms where occupants need clearly labeled controls
• Hospitality back-of-house and meeting spaces
• Wireless retrofit projects where white finish is specified

Technical Specifications

• SKU: HZ2-SWEX-W ENGRAVED
• Load Type: Non-dimming on/off, 120 VAC
• Wireless Protocol: infiNET EX 2.4 GHz mesh
• Encryption: AES-128
• Form Factor: Single-gang decora
• Finish: White
• Engraving: Custom (customer-specified at order time)
• Gateway Required: Yes (infiNET EX gateway, sold separately)
• Voltage: 120 VAC

Frequently Asked Questions

How do I specify the custom engraving text when ordering?

Engraving text should be submitted at the time of order. Contact Creation Networks directly to confirm the engraving submission process and any character limits that apply.

What is the difference between the HZ2-SWEX-W and the HZ2-SWEX-A?

The two switches are functionally identical. The HZ2-SWEX-A is Almond finish with standard factory engraving. The HZ2-SWEX-W is White finish with customer-specified custom engraving. Both are 120 VAC non-dimming switches with infiNET EX wireless.

Does the custom engraving add lead time to the order?

Custom engraved products typically require additional lead time compared to standard stock items. Contact Creation Networks for current lead time and availability before placing a time-sensitive order.
