Crestron HZ2-FP-G3-GLASS-W – Horizon 2 3-Gang Faceplate, Glass White

Product Overview

The Crestron HZ2-FP-G3-GLASS-W is a 3-gang glass faceplate for the Horizon 2 lighting control platform, finished in white glass with matching white trim. It covers three adjacent Horizon 2 in-wall devices in a standard US multi-gang electrical box, providing a premium edge-to-edge glass surface that suits contemporary and minimalist interiors. The glass construction and white finish give the plate a clean, high-end appearance distinct from standard plastic faceplates.

Product Description

Glass faceplates in the Horizon 2 family are among the most specified options for high-end residential and hospitality deployments, where the quality of wall finishes is a visible part of the overall design. The HZ2-FP-G3-GLASS-W features a tempered glass front surface with white finish across the full 3-gang width, covering three Horizon 2 dimmers, switches, keypads, or multiway remotes. The 4.73 in. H × 6.69 in. W × 0.46 in. D (120 × 170 × 12 mm) faceplate installs over all standard Horizon 2 in-wall devices in US electrical boxes. Additional faceplate variants in 1-, 2-, and 4-gang configurations and in brushed brass, dark nickel, dark bronze, brushed black, and glass black finishes are available at creationnetworks.net.

Key Features

• 3-gang faceplate for Horizon 2 in-wall devices
• White glass front surface with white trim
• Tempered glass construction for a premium finish
• Covers three adjacent Horizon 2 dimmers, switches, keypads, or multiway remotes
• Includes metal backplate for secure, flush mounting
• Dimensions: 4.73 in. H × 6.69 in. W × 0.46 in. D (120 × 170 × 12 mm)
• Weight: 7.4 oz (208 g)

Typical Applications

• Luxury residential lighting control stations with white or neutral decor
• High-end hospitality guestrooms and suites with Horizon 2 lighting systems
• Modern commercial lobbies and executive offices with white glass wall finishes
• Conference rooms requiring a premium 3-gang wall station appearance
• Horizon 2 multi-device assemblies where glass finish is specified

Technical Specifications

• Gang Count: 3
• Finish: White glass
• Trim Color: White
• Height: 4.73 in. (120 mm)
• Width: 6.69 in. (170 mm)
• Depth: 0.46 in. (12 mm)
• Weight: 7.4 oz (208 g)
• Mounting: Standard US multi-gang electrical box or low-voltage bracket
• Includes: Metal backplate
• Compatible Devices: All Horizon 2 in-wall series (HZ2-DIMEX, HZ2-SWEX, HZ2-KPCN, HZ2-KPEX, HZ2-AUX)

FAQs

Is this faceplate made of real glass?

Yes. The HZ2-FP-G3-GLASS-W uses a tempered glass front surface, which gives it a distinctly premium look and feel compared to plastic-finish faceplates.

How many Horizon 2 devices does this faceplate cover?

It covers three side-by-side Horizon 2 in-wall devices in a standard US 3-gang electrical box.

Is this faceplate compatible with all Horizon 2 in-wall devices?

Yes. It fits all Horizon 2 in-wall series products including dimmers, switches, keypads, and multiway remotes.

Are other glass faceplate finishes available?

Yes. Glass Black (HZ2-FP-G3-GLASS-B) is also available. Both are available in multiple gang counts at creationnetworks.net.
