Crestron HZ2-FP-G3-D1-W – Horizon 2 3-Gang + 1 Decorator Opening Faceplate, White

Product Overview

The Crestron HZ2-FP-G3-D1-W is a Horizon 2 combination faceplate with three Horizon 2 device openings plus one standard decorator (Decora-style) opening, in white aluminum finish. It mounts in a standard US multi-gang electrical box and provides a unified wall plate for mixed installations where Horizon 2 dimmers, switches, or keypads are installed alongside a standard decorator device such as a data outlet, USB charger, or audio connector.

Product Description

In many AV and control installations, lighting control devices share a wall box with data or AV connectivity outlets. The HZ2-FP-G3-D1-W addresses this need by combining the Horizon 2 aesthetic with accommodation for one additional standard Decora-sized device insert, allowing the finished wall assembly to present a single coordinated plate covering all four positions. This keeps the installation visually unified and avoids the mismatched appearance of combining separate faceplates. The white aluminum finish coordinates with white Horizon 2 devices and standard white wall hardware. Overall faceplate dimensions are 4.73 in. H × 6.93 in. W × 0.46 in. D (120 × 176 × 12 mm). Additional Horizon 2 faceplate configurations are available at creationnetworks.net.

Key Features

• 3 Horizon 2 device openings plus 1 standard decorator (Decora-style) opening
• White aluminum finish
• Height: 4.73 in. (120 mm); Width: 6.93 in. (176 mm); Depth: 0.46 in. (12 mm)
• Mounts in standard US multi-gang electrical box
• Weight: 7.4 oz (208 g)
• Allows mixing Horizon 2 devices with standard decorator inserts

Typical Applications

• Conference rooms combining Horizon 2 lighting controls with data or AV connectors
• Training rooms with mixed lighting and connectivity at a single wall location
• Hospitality and office installations requiring Horizon 2 devices alongside decorator devices
• Home automation wall stations mixing Horizon 2 keypads with USB or HDMI ports

Technical Specifications

• Horizon 2 Device Openings: 3
• Decorator Openings: 1 (Decora-style)
• Finish: White aluminum
• Height: 4.73 in. (120 mm)
• Width: 6.93 in. (176 mm)
• Depth: 0.46 in. (12 mm)
• Weight: 7.4 oz (208 g)
• Mounting: Standard US multi-gang electrical box
• Compatible Devices: All Horizon 2 in-wall series plus standard Decora-sized inserts

FAQs

What kind of device fits the decorator opening?

Any standard Decora-sized device insert — such as a data outlet, USB charger, HDMI wall plate, or audio jack — can be installed in the decorator opening. The device itself is not included.

Is this wider than the standard 3-gang faceplate?

Yes. The D1 designation adds one decorator opening, making the faceplate slightly wider (6.93 in.) than the standard 3-gang (6.69 in.) to accommodate the additional position.

Are Horizon 2 devices included?

No. This is the faceplate only. Horizon 2 devices and decorator inserts are sold separately.
