Crestron DM-CONN-ULTRA-RECP-XA-20 – 45-Degree Angled DigitalMedia Ultra Cable Connectors, 20 Pack

Product Overview

The Crestron DM-CONN-ULTRA-RECP-XA-20 is a pack of 20 right-angle (45-degree) receptacle connectors for Crestron DigitalMedia Ultra cables. These connectors are used where straight-entry connectors would create excessive cable bend radius or strain—particularly in shallow wall cavities, equipment rack side panels, or tight behind-display installations. The angled entry redirects the cable path to maintain clean routing without stressing the cable jacket or internal conductors.

Product Description

DigitalMedia Ultra infrastructure is designed for long-distance, high-bandwidth AV signal distribution in commercial installations. In many deployment scenarios—flush-mounted displays, shallow backboxes, densely populated equipment racks—a straight connector creates a cable loop or forces a sharp bend that can compromise signal integrity or damage the cable over time. The DM-CONN-ULTRA-RECP-XA-20 solves this by providing a 45-degree angled entry that redirects the cable at a controlled angle, maintaining the cable's minimum bend radius. Gold-plated contacts ensure reliable signal transfer, and the secure locking mechanism prevents accidental disconnection in installed environments. With 20 connectors per pack, this is well suited for large-scale DigitalMedia Ultra deployments where multiple angled connections are required across a project.

Key Features

• 45-degree right-angle angled connectors for Crestron DigitalMedia Ultra cable infrastructure
• Pack of 20 receptacles for large-scale project deployment
• Reduces cable strain and maintains minimum bend radius in tight installation spaces
• Gold-plated contacts for reliable, low-resistance signal connection
• Secure locking mechanism prevents accidental disconnection in installed environments
• Compatible with DigitalMedia Ultra transmitters and receivers
• Simplifies cable routing in shallow wall cavities, equipment racks, and behind-display locations

Typical Applications

• Behind-display DigitalMedia Ultra connections where cable exits parallel to the wall surface
• Shallow wall box or backbox installations with limited depth for cable routing
• Equipment rack installations where cable management requires side-exit routing
• Large DigitalMedia Ultra infrastructure projects requiring multiple angled termination points
• Any DM Ultra installation where straight connectors create an unacceptable bend radius

Technical Specifications

FAQs

Can these connectors be used with standard DigitalMedia (non-Ultra) cables?

No. The DM-CONN-ULTRA-RECP-XA-20 connectors are designed specifically for Crestron DigitalMedia Ultra cables and are not interchangeable with connectors from earlier DM cable generations. Verify compatibility with your specific DM Ultra hardware before ordering.

Why use a 45-degree angled connector instead of a standard straight connector?

In installations where a straight connector would require the cable to make a sharp bend immediately after the connection point—such as behind a flush-mounted display or inside a shallow wall box—the cable can be stressed or kinked over time. A 45-degree connector redirects the cable at a controlled angle, maintaining the manufacturer's specified minimum bend radius and protecting cable integrity. For project quantities or volume pricing, visit creationnetworks.net.

Are these sold in quantities smaller than 20?

The DM-CONN-ULTRA-RECP-XA-20 is sold as a 20-pack. For smaller quantity requirements, contact Creation Networks to discuss available options.
