Crestron CM2-DIMEX – Cameo 2 Forward-Phase Dimmer Expansion, Engraved
Crestron CM2-DIMEX – Cameo 2 Forward-Phase Dimmer Expansion, Engraved is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Crestron CM2-DIMEX – Cameo 2 Forward-Phase Dimmer Expansion, Engraved
Product Overview
The Crestron CM2-DIMEX is a forward-phase (TRIAC) dimmer expansion module for the Crestron Cameo 2 in-wall keypad platform. Engraved button caps are included. Forward-phase dimming is suited for incandescent, halogen, and magnetic low-voltage (MLV) loads. The module integrates with the Cameo 2 system for Cresnet-based scene and lighting control.
Product Description
The CM2-DIMEX adds forward-phase dimming capability to a Cameo 2 installation, extending the system to cover additional incandescent or halogen circuits within the same Cameo 2 multi-function wall station or standalone configuration. Forward-phase (leading-edge) dimming is the traditional TRIAC-based method that provides reliable performance with resistive and inductive load types including incandescent, tungsten halogen, and MLV transformer loads. Engraved button caps are pre-installed for immediate deployment after programming. As a Cameo 2 module, it connects via Cresnet to the Crestron processor for integration with scene control, scheduling, and full automation workflows.
Key Features
- Forward-phase (TRIAC) dimming for incandescent, halogen, and MLV loads
- Expansion module for Crestron Cameo 2 in-wall platform
- Engraved button caps included for ready-to-deploy installation
- Cresnet communication for Crestron processor integration
- Supports scene control, scheduling, and automation
- Modular design for multi-function Cameo 2 wall station configurations
Typical Applications
- Incandescent and halogen dimming expansion within Cameo 2 installations
- MLV track and accent lighting control in residential and commercial spaces
- Multi-function Cameo 2 wall stations combining dimming and other control functions
- Commercial and residential spaces with existing incandescent or halogen fixture infrastructure
Technical Specifications
- Output Type: Forward-phase (TRIAC)
- Communication: Cresnet (via Cameo 2 system)
- Platform: Crestron Cameo 2
- Engraving: Included
Frequently Asked Questions
Q: What is the difference between CM2-DIMEX and CM2-DIMUEX?
A: The CM2-DIMEX uses forward-phase (TRIAC) dimming, suited for incandescent, halogen, and MLV loads. The CM2-DIMUEX is a universal phase dimmer with auto load-type detection, supporting a wider range including ELV and dimmable LED.
Q: Are the engraved caps pre-engraved from the factory?
A: Yes, the engraved variant ships with factory-engraved button caps. For blank or custom-engraved options, refer to the CM2-DIMEX blank or custom-engraved product variants.
Q: Where can I purchase the CM2-DIMEX?
A: Available at creationnetworks.net.
