Crestron CLWI-SWEX-ANTH – Cameo Wireless In-Wall Switch, 230V, Anthracite
Crestron CLWI-SWEX-ANTH – Cameo Wireless In-Wall Switch, 230V, Anthracite is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Crestron CLWI-SWEX-ANTH – Cameo Wireless In-Wall Switch, 230V, Anth...
Product Overview
The Crestron CLWI-SWEX-ANTH is a Cameo Wireless in-wall switch for 230 VAC applications in Anthracite finish. It provides on/off switching for any load type up to 2 A via infiNET EX wireless communication, with engravable field-replaceable buttons for up to six programmable control functions.
Product Description
The CLWI-SWEX-ANTH is a relay-based on/off switch for 230V installations, compatible with incandescent, halogen, MLV, CFL, fluorescent, ELV, and LED loads. It mounts in a standard 1-gang 35 mm deep electrical box and is gangable horizontally and vertically for multi-gang configurations. Button assemblies are field-replaceable and engravable, configurable as a single rocker or up to six buttons with per-press functions including single click, double click, and hold. A faceplate from the FP-INTENSE or FP-PURE series (sold separately) and a compatible infiNET EX gateway (sold separately) are required. Note: available in the CSEA region for Macau and Hong Kong only. For ordering, visit creationnetworks.net.
Key Features
- On/off relay switch for any load type up to 2 A; 230 VAC (220–240 V, 50/60 Hz)
- Supports incandescent, tungsten-halogen, MLV, CFL, fluorescent, ELV, and LED loads
- Anthracite finish with engravable, field-replaceable buttons (up to 6 buttons)
- infiNET EX wireless, 2.4 GHz, IEEE 802.15.4; Crestron Home OS compatible
- Up to 10 white LED bargraph indicators; up to 3 functions per button press
- Gangable; 35 mm deep box compatible
- Dimensions: 2.8 × 2.9 × 1.3 in. (71 × 74 × 32 mm); weight 3.0 oz (85 g)
- Required gateway (sold separately): CEN-GWEXER, DIN-AP3MEX, or MC3
- Required faceplate (sold separately): FP-INTENSE or FP-PURE series
Typical Applications
- On/off load switching in 230V European and international commercial and residential Crestron installations
- Wireless switch control for fluorescent, CFL, and non-dimmable LED fixtures in 230V markets
- Motor and fan on/off control in international facilities using Crestron automation
- Multi-gang switch configurations using gangable Cameo modules with a single faceplate
Technical Specifications
| Specification | Value |
|---|---|
| Switch Type | Relay-based on/off |
| Load Types | Incandescent, Tungsten-Halogen, MLV, CFL, Fluorescent, ELV, LED |
| Maximum Load | 2 A |
| Power | 220–240 VAC, 50/60 Hz |
| Wireless Protocol | infiNET EX, 2.4 GHz, IEEE 802.15.4 |
| RF Range (Indoor) | 150 ft (46 m) |
| Finish | Anthracite; engravable buttons |
| Buttons | Up to 6 (configurable); up to 10 white LED indicators |
| Dimensions (H × W × D) | 2.8 × 2.9 × 1.3 in. (71 × 74 × 32 mm) |
| Weight | 3.0 oz (85 g) |
| Operating Temperature | 32°–104°F (0°–40°C) |
Frequently Asked Questions
- Is this switch suitable for North American 120V circuits?
- No. The CLWI-SWEX-ANTH is rated for 220–240 VAC and is designed for 230V international markets. For 120V North American on/off switching, use the HZ2-SWEX series.
- Can this switch control dimmable LED loads?
- The CLWI-SWEX-ANTH is an on/off relay switch and does not provide a dimming signal. It is safe to use with any LED fixture for on/off control, but will not dim LED loads. For LED dimming, use the CLWI-DIMUNEX-W (phase) or CLWI-DIMFLVEX-ANTH (0-10V).
- Is a faceplate included?
- No. A faceplate from the FP-INTENSE or FP-PURE series must be purchased separately.
