Crestron CLWI-DIMUNEX-W – Cameo Wireless Universal Dimmer, 230V, White
Product Overview
The Crestron CLWI-DIMUNEX-W is a Cameo Wireless in-wall universal phase dimmer for 230 VAC applications in White finish. It provides automatic compatibility with both forward- and reverse-phase loads including incandescent, LED, halogen, MLV, ELV, and dimmable CFL fixtures up to 450 VA, controlled wirelessly via infiNET EX 2.4 GHz.
Product Description
Designed for 230V markets, the CLWI-DIMUNEX-W uses universal phase dimming with automatic mode selection for the widest possible fixture compatibility, particularly suited to low-wattage LED loads. It mounts in a standard 1-gang 35 mm deep electrical box, with buttons configurable as a single rocker or up to six buttons supporting single click, double click, and hold functions. The default ramp rate is 5 seconds and preset fade time is 2 seconds, both software-adjustable. A faceplate from the FP-INTENSE or FP-PURE series (sold separately) and a compatible infiNET EX gateway (sold separately) are required. For ordering, visit creationnetworks.net.
Key Features
- Universal phase dimming (forward and reverse, auto-detection) for incandescent, LED, halogen, MLV, ELV, dimmable CFL
- 450 VA maximum load; 15 W minimum load; 230 VAC (220–240 V, 50/60 Hz)
- White finish with engravable, field-replaceable buttons (up to 6 buttons)
- infiNET EX wireless, 2.4 GHz, IEEE 802.15.4; Crestron Home OS compatible
- Up to 10 white LED bargraph indicators; adjustable ramp rate and fade time
- Dimensions: 2.80 × 2.80 × 1.24 in. (72 × 72 × 32 mm); weight 3.0 oz (85 g)
- Required gateway (sold separately): CEN-GWEXER, DIN-AP3MEX, or MC3
- Required faceplate (sold separately): FP-INTENSE or FP-PURE series
Typical Applications
- Universal LED dimming in 230V European and international commercial and residential projects
- Retrofit wireless dimming installations with mixed fixture types on 230V circuits
- Crestron Home lighting control in 230V markets requiring white-finish devices
- Conference rooms and offices in international facilities using Crestron automation
Technical Specifications
| Specification | Value |
|---|---|
| Dimming Technology | Universal phase (forward and reverse; auto-detection) |
| Load Types | Incandescent, LED, Tungsten-Halogen, MLV, ELV, Dimmable CFL |
| Maximum Load | 450 VA per channel |
| Minimum Load | 15 W |
| Power | 220–240 VAC, 50/60 Hz |
| Wireless Protocol | infiNET EX, 2.4 GHz, IEEE 802.15.4 |
| RF Range (Indoor) | 150 ft (46 m) |
| Finish | White; engravable buttons |
| Buttons | Up to 6 (configurable); up to 10 white LED indicators |
| Ramp Rate (default) | 5 seconds (adjustable 0.01–10 sec) |
| Preset Fade (default) | 2 seconds (adjustable 0.01–120 sec) |
| Dimensions (H × W × D) | 2.80 × 2.80 × 1.24 in. (72 × 72 × 32 mm) |
| Weight | 3.0 oz (85 g) |
| Operating Temperature | 32°–104°F (0°–40°C) |
Frequently Asked Questions
- Is this product for North American 120V installations?
- No. The CLWI-DIMUNEX-W is rated for 220–240 VAC and is designed for European and international 230V markets. For 120V universal dimming in North America, use the HZ2-DIMUEX series.
- What is the minimum load requirement?
- The CLWI-DIMUNEX-W requires a minimum load of 15 W. Do not use it with very low-wattage loads below this threshold.
- Does this dimmer work without a faceplate?
- No. A faceplate from the FP-INTENSE or FP-PURE series must be purchased separately. The module itself does not ship with a faceplate.
