Crestron CLK-YL-AYRDT216-PB-GSK – Yale Assure Touchscreen Deadbolt infiNET EX, Polished Brass, GSK

Product Overview

The Crestron CLK-YL-AYRDT216-PB-GSK is a Yale Assure Lock touchscreen deadbolt with integrated Crestron infiNET EX wireless control, in polished brass finish with a glass strike kit (GSK) included. This lock uses a backlit touchscreen keypad for PIN code entry and connects directly to a Crestron infiNET EX wireless mesh network for remote locking, unlocking, and status monitoring within a Crestron building automation or residential control system.

Product Description

The Yale Assure Touchscreen Deadbolt (model AYRDT216) replaces a standard deadbolt with a modern touchscreen-based electronic lock. The backlit touchscreen accepts PIN code entry and offers a cleaner appearance than physical keypad buttons. Crestron’s infiNET EX module is built into the lock, providing direct wireless mesh connectivity without a separate gateway device. The polished brass (PB) finish is a formal warm-gold hardware finish suited to traditional or transitional interior settings. The glass strike kit (GSK) provides hardware for glass door applications or specialized door configurations that require a different strike assembly. Crestron integration enables scheduled access, event-based locking, and real-time status monitoring from a Crestron touch panel or processor.

Key Features

• Yale Assure AYRDT216 touchscreen deadbolt — backlit touchscreen PIN entry for keyless operation
• Crestron infiNET EX integrated — direct wireless mesh connection, no separate gateway needed
• Polished brass finish — formal warm-gold finish for traditional and transitional interiors
• Glass strike kit included — appropriate strike hardware for glass door or specialty applications
• Crestron system integration — remote lock/unlock commands, status monitoring, and scheduled access

Typical Applications

• Glass door applications in Crestron-controlled residential or commercial spaces
• Traditional or transitional interior settings specifying polished brass door hardware
• Formal residential entry doors or study/library doors with Crestron automation integration
• Specialty door configurations requiring a glass strike kit in an infiNET EX-equipped installation

Technical Specifications

• Model: CLK-YL-AYRDT216-PB-GSK
• Lock Model: Yale Assure AYRDT216 Touchscreen Deadbolt
• Wireless Protocol: Crestron infiNET EX (2.4 GHz mesh)
• Finish: Polished Brass (PB)
• Keypad Type: Backlit touchscreen
• Included Hardware: Glass strike kit (GSK)

FAQs

What is the glass strike kit (GSK) for?

The glass strike kit provides the strike plate and hardware needed for doors with glass panels or specialty frame configurations that cannot use a standard strike assembly. It is included in the -GSK variant of this lock to support these specific door types.

Does this lock require a separate infiNET EX gateway?

The infiNET EX module is built into the lock itself. However, your Crestron system must include at least one infiNET EX gateway (such as a CEN-GWEXER) for the lock to join the Crestron wireless mesh network.

Is the touchscreen backlit for use in dark areas?

Yes. The AYRDT216 touchscreen is backlit, making PIN entry readable in low-light conditions. The backlight activates on touch or button press.
