Crestron CLK-YL-AYRD200-SCKA-03 – Yale Assure Deadbolt with infiNET EX, Satin Chrome Keypad, 3 Keys

Product Overview

The Crestron CLK-YL-AYRD200-SCKA-03 is a Yale Assure Lock deadbolt with integrated Crestron infiNET EX wireless control, finished in satin chrome with a keypad access panel and three physical keys included. This lock connects directly to a Crestron infiNET EX wireless mesh network, enabling integration with Crestron home automation and commercial building control systems for remote locking, unlocking, and status monitoring without a separate gateway or hub.

Product Description

The Yale Assure Lock (model AYRD200) is a Grade 2 ANSI deadbolt with a sleek contemporary design. Crestron’s infiNET EX module is built into the lock assembly, giving installers a direct connection to the Crestron wireless mesh without additional hardware. The satin chrome finish (SCKA) coordinates with modern lever and hardware sets. Three physical keys are included for users who prefer or require traditional key access alongside the keypad. The keypad allows PIN code entry for keyless entry, and the Crestron integration enables scheduled access, event-based locking, and status monitoring from a Crestron control system or touch panel.

Key Features

• Yale Assure AYRD200 deadbolt — ANSI Grade 2 deadbolt mechanism with contemporary design
• Crestron infiNET EX built in — direct wireless mesh integration, no separate gateway needed
• Satin chrome finish — modern finish that coordinates with standard AV and hardware trim
• Keypad access — PIN code entry for keyless operation
• 3 physical keys included — traditional key backup for authorized users
• Crestron system integration — remote lock/unlock, status monitoring, and scheduled access from Crestron control

Typical Applications

• Residential automation installations requiring wireless door lock control via Crestron
• Small commercial spaces and conference rooms with Crestron access control integration
• Hotel room or suite entry control in Crestron-managed hospitality systems
• Retrofit door lock upgrades in infiNET EX-equipped Crestron installations

Technical Specifications

• Model: CLK-YL-AYRD200-SCKA-03
• Lock Model: Yale Assure AYRD200 Deadbolt
• Wireless Protocol: Crestron infiNET EX (2.4 GHz mesh)
• Finish: Satin Chrome (SCKA)
• Physical Keys Included: 3
• Entry Method: Keypad PIN, physical key
• ANSI Grade: 2

FAQs

Does the CLK-YL-AYRD200-SCKA-03 require a separate infiNET EX gateway?

No. The infiNET EX wireless module is integrated into the lock. It connects directly to an existing Crestron infiNET EX mesh network. You do need at least one infiNET EX gateway (such as a CEN-GWEXER) to be present in the Crestron system that the lock will join.

Can PIN codes be managed from the Crestron control system?

Access code management depends on the Crestron programming and the Yale lock firmware. Integration typically enables lock/unlock commands and status feedback. Consult your Crestron dealer or integrator for details on PIN management capabilities in your specific Crestron configuration.

Is a separate deadbolt required if I also install a Yale lever lock?

The CLK-YL-AYRD200 is a deadbolt only. If you want both deadbolt and lever lock control, you would also install a compatible Yale lever lock with infiNET EX (such as the CLK-YL-AYRL series). Both can operate on the same Crestron infiNET EX network.
