Crestron 30 Port PoE+ Managed Switch - CEN-SWPOE-30
Crestron 30 Port PoE+ Managed Switch - CEN-SWPOE-30
Roll over image to zoom in Click on image to zoom
Crestron 30 Port PoE+ Managed Switch - CEN-SWPOE-30
Crestron 30 Port PoE+ Managed Switch - CEN-SWPOE-30
Product Questions? Ask Our Experts!
Tel: 888.230.3661 sales@creationnetworks.net Contact us today for quantity & package discounts!

Crestron 30 Port PoE+ Managed Switch - CEN-SWPOE-30

Availability: Call for Availability
Crestron SKU: CEN-SWPOE-30
No reviews
Price:
$2,172.00

Description

NETGEAR's class-leading AV network switches are designed to make integration with Crestron AV-over-IP products as simple as possible. The CEN-SWPOE-30 is a 30 port managed Ethernet switch that provides PoE+ from 24 of its ports. The four 10 Gigabit Base-X SFP+ ports enable use of transceiver modules to connect to a fiber network.

NETGEAR's class-leading AV network switches are designed to make integration with Crestron AV-over-IP products as simple as possible. The CEN-SWPOE-30 is a 30 port managed Ethernet switch that provides PoE+ from 24 of its ports. The four 10 Gigabit Base-X SFP+ ports enable use of transceiver modules to connect to a fiber network.

DM NVX and DM NAX Profiles for Quick Configuration
When configuring a DM NVX or DM NAX system, select the appropriate profile to automatically configure the CEN-SWPOE-30 with the multicast functionality required for AV-over-IP.

Web Browser Interface
Using a streamlined interface, quickly and completely configure individual ports or assign AV profiles for use with DM NVX or DM NAX systems. An advanced command line interface is also available.

Four SFP+ Ports
All SFP+ ports offer 10 Gigabit Base-X connections with support for both multimode and single-mode fiber transceiver modules, such as the SFP-10G-SR.

Power Over Ethernet+
PoE+ is supplied simultaneously across 24 ports, providing a centralized power source for numerous PoE+ powered devices and eliminating the need for cumbersome power supplies and extra wiring. Up to 30 W is provided per port up to a maximum of 480 W.

  • Class-leading NETGEAR® AV network switch
  • Rack-mount 30 port managed switch
  • Twenty-six 1000Base-T Gigabit Ethernet ports
  • Supports PoE+ (802.3at Type 2) on 24 Ethernet ports
  • Provides up to 30 W per port, 480 W total
  • Four 10 Gigabit Base-X SFP+ ports
  • Selectable DM NVX® and DM NAX™ AV-over-IP profiles
  • Layer 2 and Layer 3 managed switching functionality
  • LLDP (Link Layer Discovery Protocol) support
  • 132 Gbps switching fabric (non-blocking)
  • Simple-to-use Web browser interface
Ethernet
Ports (2) 10/100/1000Base-T auto-sensing Gigabit Ethernet
(24) 10/100/1000Base-T auto-sensing Gigabit Ethernet w/PoE+
(4) 10 Gigabit Base-X SFP+
Network Standards IEEE 802.3af, 802.3at
MAC Addresses Up to 16K
Switch Fabric 132 Gbps non-blocking
Lite Layer 3 Package
Management Out-of-band;
IT Web GUI (main);
HTTPs, CLI, Telnet, SSH;
SNMP, MIBs, RSPAN;
Radius users, TACACS+
IPv4/IPv6 ACL and QoS Ingress/egress;
1 Kbps shaping, time-based;
Single rate policing
IPv4/IPv6 Multicast Filtering Automated IGMP between switches;
IGMPv3 MLDv2 snooping, proxy ASM and SSM;
IGMPv1, v2 querier (compatible with v3);
Control packet flooding
IPv4/IPv6 Policing and Convergence Auto-VoIP;
Policy-based routing;
LLDP-MED;
IEEE 1588 PTPv2
IPv4/IPv6 Authentication Security Successive tiering (DOT1X, MAB, Captive portal);
DHCP snooping;
Dynamic ARP inspection;
IP source guard
IPv4/IPv6 Static Routing Port, subnet, VLAN routing;
Multicast static routes;
DHCPv4 server;
DHCP relay;
Stateful DHCPv6 Server
IPv4/IPv6 Dynamic Routing IPv4: RIP;
IPv4/IPv6: PIM-SM, PIM-DM, SSM
Spanning Tree Green Ethernet STP, MTP, RSTP;
PV(R)STP;
BPDU/STRG;
EEE 802.3az
VLANs Static, dynamic, voice, MAC;
GVRP/GMRP;
Double VLAN mode;
Private VLANs
Indicators
POWER (1) green LED, indicates operating power supplied via main power input
FAN (1) green LED, indicates fan is in operation
PoE MAX (1) green LED, indicates the unit is supplying the maximum amount of PoE
OOB

(2) green LEDs for Ethernet port, indicates Ethernet link status for out-of-band (service) port
1-24 (2) LEDs per each (24) Ethernet port, left (green) LEDs indicate Ethernet link status for each corresponding port, right (blue) LEDs indicate PoE for each corresponding port
25-26

(1) green LED per each (2) Ethernet port, indicates Ethernet link status for each corresponding port.
27-30

(1) green LED per SFP+ port, indicates active connection
Connectors
OOB (1) 8-wire RJ45, female;
10/100/1000Base-T Ethernet port
CONSOLE (1) 8-wire RJ45, female
USB-C USB-C® port, female
100-240V (1) power connector
USB USB Type A, female
LED EXT USB-C port, female
1-24 (24) 8-wire RJ45, female;
10/100/1000Base-T Ethernet ports and PoE Power Sourcing Equipment (PSE) outputs;
Supports IEEE 802.3at Type 2 PoE+ power sourcing from any ports up to the maximum specified power capabilities;
Maximum 30 Watts per port, 480 Watts total
25-26

(2) 8-wire RJ45, female;
10/100/1000Base-T Ethernet ports.
27-30

(4) SFP+ ports, female;
10 Gigabit Base-X SFP+
Power Requirements
Main Power 6.4-2.5 Amps @ 100–240 Volts AC, 50/60Hz
Power Consumption Max PoE: 614 W
No PoE: 46.8 W
Standby: 33.90 W
Environmental
Temperature 32° to 122° F (0° to 50° C)
Humidity 10% to 90% RH (non‑condensing)
Ambient Noise 42 dB at 77° F (25° C)
Construction
Chassis Metal, black finish, fan-cooled, vented sides
Mounting Freestanding or 1U 19-inch rack-mountable with reversible rack ears
Dimensions
Height 1.7 in. (43.2 mm)
Width 17.32 in. (440 mm)
Depth 10.11 in. (257 mm)
Weight
12.02 lb (5.45 kg)
