Creation Networks Rack Elevation Design CAD for a 41u+ System
A rack elevation drawing for a 41U+ AV rack — $250. Our engineers lay out every piece of gear in your rack so it fits, gets serviced easily and stays cool. You get a CAD drawing your installer can build from, plus a full hardware list.
What you get
- Rack elevation CAD drawing showing where every device mounts
- Equipment placement planned for airflow and thermal management — the part most racks get wrong
- Logical, serviceable layout: power, network and signal gear grouped the way techs expect
- A complete hardware list, including the rack and the accessories your build needs
How it works
- Order the design that matches your rack size
- We contact you for your equipment list and the room dimensions where the rack will live
- Our team builds the design and sends you the drawing and hardware list
Buy the rack from us and the design is free
If you purchase the rack from Creation Networks, the cost of this design is credited against your invoice.
Pick your rack size
| Rack size | Price |
|---|---|
| 1–20U rack | $150 |
| 21–40U rack | $220 |
| 41U+ rack | $250 |
Why Creation Networks
CTS-D certified, with 5,000+ AV systems installed nationwide since 2006 for corporate, government, education and healthcare clients. Our techs have seen the rookie mistakes so your team doesn't have to make them.
Common questions
What do you need from me? Your equipment list and the dimensions of the space where the rack will sit.
Not sure of your rack size? Pick the size closest to your equipment count. If it turns out you need a larger or smaller rack, call us and we'll sort it out.
Do you install the rack too? Yes. Add Onsite Installation, or have your own team build it from our drawing.
Questions before you order? Call 888.230.3661 or email sales@creationnetworks.net.
