Community IV6-118S is a single 18-inch subwoofer.
The IV6-118S is a high power 1 x 18" compact, direct-radiating subwoofer designed to complement the full range IV6-1122 elements in any array configuration with deep, impactful low frequency support. Large, balanced ports provide optimal enclosure tuning and even air pressure distribution to the driver cone, reducing distortion and extending system longevity. A FEA-optimized ferrite motor with long linear excursion capabilities provides deep bass response for the enclosure’s size. With 800W @ 8 Ohms of continuous power handling (80V), the IV6-118S subwoofer can be conveniently driven by the same size power amplifier as the IV6-1122 full-range array elements.
Features
- Long excursion ferrite LF driver with FEA-optimized motor and symmetric movement suspension
- Matched-size enclosure and aligned suspension point for seamless flown array integration
- 800W continuous power handling (3200W peak)
- High sensitivity design minimizes power compression losses and required amplifier size
Specifications
- Transducer: 1 x 18" (457mm) double-treated cone with 4" (102mm) inner/outer wound voice coil, ferrite construction
- Operating Range: 37 Hz to 132 Hz
- Continuous Power Handling @ Nominal Impedance: 80V,800W @ 8 ohms
- Sensitivity (1W/1m): 102 dB
- Finish: Black or White low gloss, uniformly textured painted 15mm Baltic Birch plywood with powder-coated steel grille; Outdoor(WR): 15mm PolyGlas, Grey, Black or White heavily textured exterior-rated coating with powder-coated marine-grade aluminum
- Dimensions: 20.00" x 28.12" x 28.08" (508 x 714 x 713 mm)
