ClearTouch CTI-7043XT-UH20 43" 7000XT Interactive Flat Panel Display

Product Overview

The ClearTouch CTI-7043XT-UH20 is a 43 inch interactive flat panel display sized for huddle rooms, small meeting spaces, and tabletop deployments. As a compact small room interactive display, it combines a 3840 x 2160 ADS panel with projected capacitive (PCAP) touch supporting up to 40 points under Windows. This huddle room interactive display runs Android 11 onboard and accepts an optional OPS slot-in PC for Windows workflows. Built to pair with the ClearTouch Mini-Convertible mobile stand, it adapts to both wall-mounted and convertible tabletop interactive display use.

Product Description

The 7043XT brings full 4K interactivity to spaces where an 86" panel is impractical. The ADS panel delivers wide 178° viewing, 450 cd/m² brightness, and a fine 0.2451 mm pixel pitch, keeping text and shared content crisp at close viewing distances typical of huddle rooms. PCAP touch supports 40 points under Windows and 32 under Android, with 4096-level pressure sensitivity and palm rejection for natural inking. The 4 mm toughened glass is rated at Mohs level 9, and both active and passive pens are supported, with ±1 mm accuracy for the active pen. The onboard Android 11 system (quad A53 plus quad A73, Mali G52 MP8 GPU, 4GB RAM, 32GB ROM) handles whiteboarding and casting without an external source, while the OPS slot accepts the optional CTI-PCOPS-PC15 module for native Windows operation such as Teams or Zoom Rooms. Connectivity covers three HDMI inputs, HDMI out, mixed USB 2.0 and 3.0, USB-C input, dual touch ports, SPDIF, and RS-232, with RJ45 in and out for networked control. Wireless includes Bluetooth 5.0 and 802.11ax Wi-Fi via the included module. Pairing with the ClearTouch Mini-Convertible mobile stand turns the panel into a rollable, tilting tabletop surface for flexible room layouts. For other models in this product family, see the ClearTouch collection.

Key Features

• 43" 4K ADS Panel — The ADS panel delivers 3840 x 2160 resolution with a wide 178° viewing angle and 1.07 billion colors for accurate shared content.
• 40-Point PCAP Touch — The PCAP capacitive touch panel supports 40 touch points under Windows and 32 under Android with 4096-level pressure sensitivity.
• Mohs Level 9 Toughened Glass — The 4 mm hardened surface resists scratching and physical wear in shared, high-use small rooms.
• Active and Passive Pen Support — Both pen types are supported, with ±1 mm accuracy on the active pen and ±2 mm on the passive pen for precise annotation.
• Onboard Android 11 — The integrated octa-core Android 11 system runs whiteboarding, casting, and apps without an external source.
• Optional OPS PC Slot — This interactive panel with OPS slot accepts the optional CTI-PCOPS-PC15 module for native Windows workflows.
• Convertible Stand Ready — The panel is built to pair with the ClearTouch Mini-Convertible mobile stand for a rollable tabletop interactive display configuration.
• Modern Wireless — Bluetooth 5.0 and 802.11ax Wi-Fi are included for casting and peripheral connectivity.
• Networked Control — RS-232 plus RJ45 in and out support integration with room control and remote management systems.

Typical Applications

• Huddle rooms and small meeting spaces
• Conference rooms
• Training rooms and breakout spaces
• Government and public-sector workspaces
• Commercial meeting spaces
• Multi-purpose and flexible-layout rooms
• House of worship small-group spaces

Technical Specifications

Frequently Asked Questions

Is this panel large enough for a conference room?

At 43" it is sized for huddle rooms, small meeting spaces, and tabletop use. For larger conference rooms and boardrooms, consider a larger model in the ClearTouch collection.

Does it need an external computer?

No. The onboard Android 11 system handles whiteboarding and casting. For native Windows workflows, add the optional CTI-PCOPS-PC15 OPS module into the slot.

Can I use it on a mobile stand?

Yes. The panel is built to pair with the ClearTouch Mini-Convertible mobile stand for a rollable, tilting tabletop configuration, and it also wall-mounts to a 400 x 300 mm VESA pattern.

How does it integrate with AV control systems?

The display supports RS-232 control and includes RJ45 in and out ports for networked control and remote management within a managed AV environment.

What pens does it support?

Both active and passive pens are supported, with ±1 mm accuracy on the active pen, alongside 40-point PCAP touch and 4096-level pressure sensitivity.

What is the warranty?

The panel carries a 3-year standard warranty, with 5 years available with purchase. Contact Creation Networks for full warranty terms.
