Cisco Webex Board 85 Wall Stand CS-BOARD85-WS= – Spare Complete Wall Stand

Product Overview

CS-BOARD85-WS= is Cisco's service part number for the complete wall stand supplied with the Cisco Webex Board 85S. The equals sign marks it as a spare or service unit: this is the stand alone, with no board, camera or electronics. Worth knowing before ordering — Cisco never built a first-generation 85-inch board, so despite the shortened "Board 85" wording used in distributor listings, the 85-inch size exists only as the 85S, and this stand belongs to it. Cisco placed the 85S and its mounting accessories end-of-sale on May 10, 2022 with a last date of support of May 31, 2027, and migrates the mounts to the Board Pro 75 equivalents.

Product Description

The wall stand is the middle option of the three mounting formats Cisco published for the 85S, sitting between the floor stand and the flush wall mount kit. It takes the panel weight partly through the floor while still positioning the board against the wall, which suits rooms where the wall build-up is unknown or where a full 100 kg panel load cannot be certified onto studwork. Cisco publishes a dedicated wall stand installation guide and CAD drawings for the 85S, so the fixing detail can be resolved before the crew arrives.

Treat the logistics as the real project constraint. The board alone is 100 kg [220 lb], and Cisco gives the packaged weight with the wall stand as 213 kg [470 lb] — against 233 kg with the floor stand and 199 kg with the wall mount kit. That is lift-equipment territory, and Cisco also publishes a transport frame, CS-BRD85-FRM=, specifically for moving an 85-inch board through a finished building. Order the frame separately if the panel has to come off its existing position and travel.

Because the panel is unsupported after May 31, 2027, most buyers ordering a spare stand are keeping a working hall or classroom installation on the wall until a planned Board Pro 75 refresh. Creation Networks lists this stand with the rest of the Cisco display mounts, the boards it carries under interactive displays, and the rooms it serves under large room solutions.

Key Features

• Complete stand as a service part — Cisco describes CS-BOARD85-WS= as the complete wall stand for the Webex Board 85S, so the kit arrives whole rather than as loose brackets to be matched against an old assembly.
• 85-inch size only exists as the 85S — Cisco produced no first-generation 85-inch board, so this stand fits the 85S and there is no earlier panel it could be mismatched against.
• Wall-positioned without full wall loading — The stand holds the board against the wall while carrying weight to the floor, which suits partition and glazed walls that cannot be certified for a 100 kg panel.
• Published packaged weight — Cisco gives 213 kg [470 lb] packaged with the wall stand, so lifting equipment and access routes can be booked from published data.
• Cisco installation documentation — A dedicated 85S wall stand installation guide and CAD drawings are published, giving the crew fixing detail before the site visit.
• Transport frame available separately — CS-BRD85-FRM= is Cisco's transport frame for the 85-inch board, which matters whenever the panel has to be moved rather than simply re-hung.

Typical Applications

• Auditorium — mounts an 85-inch collaboration board in the largest spaces Cisco targets with this size.
• Training room — keeps a teaching panel wall-positioned in a room where the wall build-up cannot be verified.
• House of worship — a stand-supported mount avoids fixing into a wall surface that must not be penetrated.
• All-hands room — restores the mounting for a large-format board serving a full-room audience.

Technical Specifications
