Christie XP Series LED 1.25mm P3 LED Video Wall Cabinet - XP1.25 (TAA)
What is the Christie XP Series LED 1.25mm LED video wall cabinet?
The Christie XP Series LED 1.25mm is a 1.25mm TAA-compliant direct-view LED cabinet from Christie Digital, built for precise color and clean grayscale at any brightness. XP Series pairs P3 color and 24-bit processing with a 30 mm ultra-slim die-cast cabinet and a 10-year warranty. This pitch suits boardrooms, government operations centers, and lobby feature walls.
What is included?
One Christie XP Series LED 1.25mm cabinet in the format you select: 16:9 landscape or 4:9 portrait
Cable Link (CL) cabinet interconnect
Christie Link E1000 controller, Octroller, and power are quoted with the wall
How does the Christie XP Series LED 1.25mm work?
Christie's VividLife processing platform drives XP Series with a 120 Hz input and 7,680 Hz output refresh, so fast motion stays flicker-free on camera and in person. Every cabinet is pixel-calibrated at the factory, and automatic color and brightness matching plus software cabinet mapping keep the wall uniform with very little on-site work. A dedicated low-brightness calibration (500 nits) keeps grayscale clean in dark control rooms and dark rides.
The Christie Link E1000 controller takes HDMI 2.0 and DisplayPort 1.2 sources up to dual 4K/60 or 4K/120 and sends them over 40 Gb QSFP+ fiber to the wall, with Cat6 daisy chaining between cabinets. Modules connect without cables, and the cabinets support flat walls and faceted concave or convex curves. Compare the 0.9mm, 1.5mm, 1.8mm, 2.5mm, 3.8mm cabinets, or browse more video walls.
What are the key features of the Christie XP Series LED 1.25mm?
1.25mm pixel pitch — 480 x 270 pixels per landscape cabinet.
1,000 nits maximum, with 500-nit low-brightness calibration.
P3 color with 18-bit grayscale and 24-bit processing.
7,680 Hz refresh and 120 Hz input.
30 mm ultra-slim cabinet in 16:9 or 4:9 formats.
Curves — concave and convex faceted installs.
TAA-compliant and rated for 24/7 operation.
10-year warranty on parts and labor.
Where is the Christie XP Series LED 1.25mm typically used?
Government and utility control rooms
Theme park dark rides and attractions
Corporate lobbies and briefing centers
Museums and immersive exhibits
Energy and utility operations centers
Technical Specifications
| Model | XP LED 1.25 (XP1.25) |
| Pixel pitch | 1.25mm |
| LED technology | Flip-chip SMD |
| Brightness (calibrated) | 1,000 nits maximum; 500 nits low-brightness calibration |
| Color | P3 ≥95%, 18-bit grayscale, 24-bit processing, 4:4:4 |
| Refresh rate | 120 Hz input; 7,680 Hz output |
| Scan rate | 1/46 |
| Contrast | Greater than 5,000:1 at 10 lux |
| Viewing angle | ≥160° H / ≥160° V |
| Color temperature | 2,700–9,500 K |
| Cabinet resolution | Landscape 480 x 270 px; portrait 240 x 540 px |
| Cabinets for Full HD | 4 x 4 (landscape) |
| Cabinet size | Landscape 600 x 337.5 x 30 mm (16:9); portrait 300 x 675 x 30 mm (4:9) |
| Cabinet weight | About 11.2 lbs (5.06 kg) per cabinet; 25 kg/m² |
| Power | 300 W/m² max, 140 W/m² typical at 800 nits; 100–240 VAC; optional redundant AC, N+1 hot-swap remote power |
| Signal | Christie Link E1000 controller: 2x HDMI 2.0, 2x DisplayPort 1.2 (HDCP 2.2); Octroller with 40 Gb QSFP+ fiber and Cat6 daisy chain |
| Signal formats | Single 4K/60, dual 4K/60 (4K/120), dual 2K x 2K/120, 3D at 60 Hz per eye |
| Environment | Indoor, 32–104°F (0–40°C); IP40 front |
| LED lifespan | 100,000 hours to 50% brightness, 24/7 |
| Installation | Flat, concave, convex faceted curves; front serviceable; ADA-compliant |
| Compliance | TAA-compliant; UL60950, FCC, CE |
| Warranty | 10-year parts and labor limited warranty |
Christie lists XP Series specifications as preliminary; confirm final specs with us before ordering.
Frequently Asked Questions
How is XP Series LED priced?
Walls are quoted as a system based on size, pitch, protection level, and controller. Send us your wall size and viewing distance and we'll build the bill of materials.
Is XP Series TAA-compliant?
Yes. The XP Series is TAA-compliant and suited to federal, state, and local government projects.
What's the difference between landscape and portrait cabinets?
Landscape cabinets are 600 x 337.5 mm (16:9). Portrait cabinets are 300 x 675 mm (4:9), which helps fit walls to tall or narrow openings. Both can be mixed in one design.
What redundancy options are available?
Christie offers standard, assured, and maximum protection levels, from optional redundant AC power up to full redundancy with N+1 hot-swappable remote power.
How many cabinets do I need for Full HD?
At 1.25mm, a 4 x 4 grid of landscape cabinets gives 1920 x 1080.
