Christie Mystique Essentials Edition - 156-126100-01

Product Overview

Christie Mystique Essentials Edition (156-126100-01) is a single-camera, camera-based warping and blending tool that automatically aligns multi-projector systems on flat screens and surfaces. It supports up to 12 projectors in a 2x3 double-stacked configuration and auto-calibrates in under two minutes per projector. Working with Christie Twist, it turns a job that once took hours of manual adjustment into a guided, repeatable process. It is aimed at staging companies, integrators, and end users who need fast, accurate stacks and blends on temporary or fixed installations.

Product Description

Mystique Essentials uses a camera to measure the projected image and computes the warp and blend corrections automatically, with a step-by-step Windows interface providing real-time feedback. No specialist alignment experience is required to achieve professional results on complex arrays. Beyond geometry, Mystique adds automated color and brightness uniformity: with version 2.5 or later and a single color camera, the system matches color and brightness across the array at a click (supported on Boxer 4K30, Mirage 304K, Griffyn 4K32-RGB, D4K40-RGB, Mirage 4K40-RGB, Mirage SST, and Mirage SST-6P; results are bounded by the lowest-performing projector). Background compensation uses the color camera to detect contrast differences on the projection surface and automatically corrects for smudges, dirt, or surface anomalies. The optional Christie Guardian feature continuously monitors a blended system and re-calibrates invisibly in real time if misalignment is detected — even while content plays. Camera options include a 5MP CCD PoE Ethernet camera with a choice of 5.0mm, 8.0mm, 12.0mm, or 16.0mm lenses for short, mid, and long-throw positions.

Key Features

• Automatic Camera-Based Alignment — calibrates warp and blend in under two minutes per projector.
• Up to 12 Projectors — supports a 2x3 blended configuration, double-stacked.
• Guided Workflow — step-by-step Windows interface with real-time camera feedback; no expert required.
• Automated Color and Brightness Uniformity — one-click matching across the array (Mystique v2.5+, color camera, supported projectors).
• Background Compensation — corrects for surface smudges, dirt, and contrast anomalies automatically.
• Christie Guardian Option — continuous monitoring with invisible real-time re-alignment during playback.
• Flexible Camera/Lens Choices — 5MP PoE camera with 5, 8, 12, or 16mm lens options.
• Twist Integration — drives Christie Twist for the underlying warp and blend.

Typical Applications

Mystique Essentials serves projection mapping and multi-projector alignment in live events and staging, corporate and broadcast productions, planetariums, theme parks, and fixed installations using flat screens. Pair it with Christie GigE camera kits and Twist from our Christie Digital collection.

Technical Specifications

Specifications sourced from Christie vendor data. Unlisted values are omitted rather than estimated.

Frequently Asked Questions

How many projectors can Essentials Edition align?
Up to 12 — a 2x3 blended array that can be double-stacked. Larger or curved-surface systems call for Mystique Pro Venue or higher editions.

Does it work on curved screens?
No. Essentials Edition supports flat screens and surfaces only.

Is a camera included?
The system uses a 5MP PoE Ethernet camera with a choice of 5, 8, 12, or 16mm lenses; confirm the camera kit configuration for your throw distance when ordering.

What is Christie Guardian?
An optional feature that continuously monitors the blended system and re-calibrates automatically and invisibly if misalignment is detected, even while content is playing.

Do I also need Christie Twist?
Mystique works in conjunction with Christie Twist, which applies the warp and blend that Mystique computes.
