Christie Crimson WU31 31,500 lumen WUXGA Laser 3DLP Projector - 165-014106-02

Product Overview

The Christie Crimson WU31 (165-014106-02) is a 31,500 center lumen WUXGA 3DLP laser phosphor projector engineered for large venues, live events, and high-use environments. Its IP5X-sealed solid-state laser light source delivers up to 20,000 hours of virtually maintenance-free operation in a rugged, compact chassis. Christie BoldColor Technology and TruLife electronics combine high brightness with enhanced color saturation and ultra-fast processing. Creation Networks supplies the Crimson Series with lenses and accessories from the Christie Digital range.

Product Description

Crimson WU31 was designed from the ground up as a rental-staging and large-venue workhorse. The 3DLP light engine uses light more efficiently than single-chip designs, and BoldColor Technology lifts color performance and saturation beyond standard laser phosphor projection. Christie TruLife electronics drive WUXGA (1920 x 1200) at 60 Hz standard, with an optional 120 Hz upgrade for motion-critical content. Christie Twist warping and blending is built in for multi-projector installs, and the projector is compatible with Christie Mystique automated camera-based alignment — including the Christie Guardian option, which corrects blended arrays in real time even while content plays. The fully omnidirectional chassis installs at any angle, and the ILS lens mount accepts existing Christie M and J Series lenses, protecting prior lens investments. Fiber connectivity via Christie Link supports up to 40 Gbit/s point-to-point on a single cable, with QSFP+ modules and the High Bandwidth Multi-Input Card (HBMIC) available, plus an optional Christie Terra SDVoE input board for AV-over-IP signal delivery and control over 10G Ethernet.

Key Features

• 31,500 Center Lumens — high brightness for big screens, long throws, and high ambient light venues.
• 3DLP Image Fidelity — efficient light use and higher color contrast for true-to-life large-format visuals.
• Christie BoldColor Technology — enhanced color performance and saturation over standard laser phosphor projection.
• 20,000-Hour Laser Source — IP5X-sealed solid-state illumination for years of low-maintenance operation.
• TruLife Electronics — WUXGA at 60 Hz standard with optional 120 Hz high frame rate processing.
• Built-In Christie Twist — onboard warping and blending speeds multi-projector deployment.
• Mystique and Guardian Support — automated camera-based alignment with optional real-time invisible blend correction during playback.
• Omnidirectional Installation — unrestricted mounting orientation for creative staging and fixed installs.
• M/J Series ILS Lens Compatibility — reuse existing Christie lenses with intelligent motorized lens recall.
• Christie Link Fiber — up to 40 Gbit/s point-to-point on a single cable; optional Terra SDVoE input board for AV-over-IP.

Typical Applications

The Crimson WU31 targets live event staging and rental, large auditoriums, houses of worship, theme park and attraction projection, projection mapping on architecture and scenery, and large lecture halls. Its sealed laser source and omnidirectional design suit continuous-duty installations where lamp maintenance is impractical.

Technical Specifications

Specifications sourced from Christie vendor data. Unlisted values are omitted rather than estimated.

Frequently Asked Questions

Can I use my existing Christie lenses with the Crimson WU31?
Yes. The ILS lens mount is compatible with existing Christie M and J Series lenses, with automatic recognition and repeatable recall of offset, zoom, and focus positions.

How does it handle multi-projector blends?
Christie Twist is built in for warping and blending. Adding Mystique automates camera-based alignment, and the Guardian option keeps blended arrays corrected in real time without interrupting content.

What signal transport options exist for long cable runs?
Christie Link provides full-bandwidth point-to-point fiber up to 40 Gbit/s on a single cable via QSFP+ modules and the HBMIC card. An optional Christie Terra SDVoE input board delivers AV-over-IP with scaling and control over 10G Ethernet.

Is the WU31 suitable for permanent 24/7 installation?
Yes. The IP5X-sealed laser source is rated up to 20,000 hours and the chassis is omnidirectional, making it appropriate for fixed attraction and venue installs as well as rental staging. Contact Creation Networks to request a quote and lens recommendation.
