Chief Odm Xlfp Ceiling Single Mount - OXCM1U

Product Overview

The Chief OXCM1U is an outdoor ceiling and pedestal display mount built to withstand rain, humidity, ocean air, sun exposure, and high winds. It is wind-compatible to 2000 ft-lbs maximum moment force, supporting a wide range of install configurations against local safety requirements. The three-piece mount, column, and plate design suits demanding outdoor commercial and public-space deployments. An included wind deflector adds protection for displays not originally designed for wind exposure.

Product Description

The OXCM1U outdoor ceiling and pedestal mount is engineered for permanent outdoor display installations exposed to the elements. Its weatherproof design meets UL 2442 Part 2 for outdoor use, with corrosion-resistant paint, UV-rated plastics, and stainless-steel hardware. The mount ships in three pieces — the mount, column, and plate — for customization to specific installation requirements. A four-step installation process keeps each piece separate for a safer, more manageable lifting load. A tilt range of +7.6 to -20 degrees uses set locking points to eliminate guesswork when aligning multiple displays. The unit can be ceiling or floor (pedestal) mounted, and the included wind deflector shields technology that may not be rated for direct wind exposure. A universal interface fits most indoor and outdoor displays up to an 800 x 400 mm VESA pattern. For additional configuration support, contact Legrand AV Customer Care, and browse comparable outdoor and ceiling mounts in the Chief collection.

Key Features

• Weatherproof construction — Meets UL 2442 Part 2 for outdoor use with corrosion-resistant paint, UV-rated plastics, and stainless-steel hardware.
• High wind rating — Wind-compatible to 2000 ft-lbs maximum moment force for a wide range of install configurations.
• Three-piece design — Separate mount, column, and plate allow customization to specific installation requirements.
• Safer installation — A four-step process keeps each component separate for a more manageable lifting load.
• Repeatable tilt — A +7.6 to -20 degree tilt range with set locking points eliminates guesswork across multiple displays.
• Universal display fit — Accepts most indoor and outdoor displays up to an 800 x 400 mm VESA pattern.
• Ceiling or pedestal mount — Installs from the ceiling or floor to suit the site layout.

Typical Applications

• Outdoor commercial signage and wayfinding
• Stadium, arena, and broadcast studio exterior displays
• Government space and transit hub displays
• House of worship outdoor and courtyard displays
• Multi-purpose outdoor commercial meeting space

Technical Specifications

Frequently Asked Questions

Is the OXCM1U rated for outdoor installation?
Yes. Its weatherproof design meets UL 2442 Part 2 for outdoor use, with corrosion-resistant paint, UV-rated plastics, and stainless-steel hardware.

How much wind can the mount handle?
It is wind-compatible to 2000 ft-lbs maximum moment force. Contact Legrand AV Customer Care to confirm your configuration meets local safety requirements.

What displays are compatible?
The universal interface fits most indoor and outdoor displays up to an 800 x 400 mm VESA pattern. Verify your display's VESA pattern and weight before ordering.

Can it be floor mounted instead of ceiling mounted?
Yes. The OXCM1U can be installed from the ceiling or as a floor/pedestal mount depending on your site layout.

Does it help protect displays from wind?
An included wind deflector adds a layer of protection for displays that may not be designed for direct wind exposure.

What warranty applies?
The mount is covered under the Legrand AV / Chief manufacturer warranty. Contact Creation Networks for current warranty terms and support.
