Chief CEILING MOUNT ACCESSORY KIT - CMA700W

Product Overview

The Chief CMA700W ceiling mount accessory kit is the white-finish version of Chief's complete structural ceiling installation bundle. It is built for conference rooms, auditoriums, and commercial meeting spaces with white ceilings where a projector or display drops from a hard structural deck. The kit pairs a ceiling plate with an adjustable extension column to set drop height. It uses the standard 1.5-inch NPT interface found across the Chief ceiling mount line.

Product Description

The CMA700W collects the accessories required for a structural ceiling installation into a single, cost-effective kit finished in white to blend with painted and light-colored ceilings. It includes a 6 x 6 inch ceiling plate that fastens to the structure and an adjustable extension column that spans 12 to 18 inches (305 to 457 mm) to set the fixture at the correct height. The assembly uses a 1.5-inch NPT thread, the common standard across Chief projector and display mounts, so it integrates with a wide range of compatible heads and couplers. Because it mounts to a hard structural ceiling rather than a suspended tile grid, the kit suits higher-load and permanent installations. The product photo shows the black version, as a photo of the white version is not available; the CMA700W ships in white. The black version is available as the CMA700, and additional columns and plates are in the full Chief collection at Creation Networks.

Key Features

• Complete kit — Bundles the accessories for a structural ceiling installation in one order.
• White finish — Blends with painted and light-colored ceilings.
• Adjustable drop — Extension column spans 12 to 18 inches (305 to 457 mm) to set fixture height.
• Structural ceiling plate — Includes a 6 x 6 inch plate for attachment to the building structure.
• Standard interface — Uses 1.5-inch NPT, compatible across the Chief ceiling mount line.
