Chief 43" Portrait On-Wall Kiosk W/Glass Wht - LW43UWPG

Product Overview

The Chief Impact On-Wall Kiosk with protective glass White is a 43-inch portrait digital signage enclosure that adds factory-bonded tempered glass to shield the display in high-traffic commercial spaces. The depth-adjustable frame and low wall protrusion make it well suited to retail, transit, and public-facing signage where display protection and a clean profile are priorities. The white finish integrates cleanly into commercial interiors.

Product Description

The Impact On-Wall Kiosk brings flexibility to the digital signage enclosure market while maintaining a clean aesthetic for a variety of commercial environments. Integrated 5/32" tempered glass is factory bonded to the enclosure with industrial adhesives, protecting the LCD display from sharp objects and common impacts. The depth-adjustable exterior frame supports a wide range of displays, and a wall protrusion of 4" (101mm) or less can be achieved using flat panels less than 2.75" (70mm) deep. An integrated wall reveal compensates for uneven walls to keep the frame plumb and provides passive cooling. The exclusive hinge design keeps the display mounted to the frame when opened for service access, and reversible hinges let installers avoid obstructions. A secure engagement latch accepts tamperproof hardware. Middle Atlantic Lever Lock technology is integrated so storage mounts without cutting into walls, and the large empty center backing is compatible with PAC525 and PAC526 series in-wall boxes, including power options. This white 43-inch portrait model is built for commercial-grade signage deployment.

Key Features

• Factory-bonded tempered glass — Integrated 5/32" tempered glass is factory bonded to protect the LCD display from impacts and sharp objects.
• Low wall protrusion — A wall protrusion of 4" (101mm) or less is achievable with flat panels under 2.75" (70mm) deep.
• Depth-adjustable frame — The exterior frame adjusts to support a wide range of commercial displays.
• Serviceable hinge design — The display stays mounted to the frame when opened, and reversible hinges help installers avoid obstructions.
• Passive cooling — An integrated wall reveal keeps the frame plumb on uneven walls and provides passive cooling.
• Tamperproof latch — The engagement latch accepts tamperproof hardware for secure public-facing installations.
• In-wall box compatible — Compatible with PAC525 and PAC526 series in-wall boxes, including power options, via the large empty center backing.

Typical Applications

• Retail and commercial meeting space signage
• House of worship displays
• Government space and public-area kiosks
• Multi-purpose room and training room signage
• Conference room wayfinding displays

Technical Specifications

Frequently Asked Questions

What size displays does this enclosure support?
The depth-adjustable frame fits panels in the 43-inch portrait class. Bezel size varies by panel, so reference the Chief technical drawings and specification sheet for your display's image diagonal.

How low can the wall protrusion be?
A wall protrusion of 4" (101mm) or less can be achieved when using flat panels less than 2.75" (70mm) in depth.

Does the glass protect the display?
Yes. The integrated 5/32" tempered glass is factory bonded with industrial adhesives to protect the LCD from sharp objects and common impacts.

Can power and cabling be concealed?
Yes. The large empty center backing is compatible with PAC525 and PAC526 series in-wall boxes, including power options.

How is the display serviced?
The exclusive design keeps the display mounted to the frame when opened, and reversible hinges let you route service access around obstructions.

What warranty applies?
This Chief enclosure is covered under the Legrand AV / Chief manufacturer warranty. Contact Creation Networks for current warranty terms and support.

Compare related Chief glass on-wall kiosks: LW43UBPG Portrait Glass, LW42UWPG Portrait Glass, LW42UBPG Portrait Glass. Browse the full Chief collection at Creation Networks.
