ChamSys GeNetix GN2
Product Overview
The ChamSys GeNetix GN2 is a compact two-port Ethernet-to-DMX node compatible with any console supporting Art-Net and sACN. It can also act as a USB interface for MagicQ PC systems, unlocking MagicQ into Core mode over USB-C or network. Both DMX ports support RDM and configure as input or output. The node is powered by PoE or USB-C and mounts standalone, on a truss via its M12 receiver, or on a DIN rail.
Product Description
The GeNetix GN2 is the smallest node in the GeNetix DMX node range, converting Art-Net and sACN network data into 2 ports of RDM DMX, each configurable as input or output. DMX timings are fully configurable, including refresh rate, break time, frame time, and MAB, and the node supports per-port merging across HTP, LTP, lowest IP, and highest IP modes. It stores user scenes recorded from incoming Art-Net or sACN data and supports DMX Fallback for redundancy, where fixtures are looped across two ports so a single broken cable does not interrupt the universe.
Configuration is handled locally on the front-panel display and encoder, remotely through the onboard web server, or from a ChamSys console. The GN2 is powered either over PoE on Port 1 or from its USB-C port. When connected to a MagicQ PC system over USB-C or network, it unlocks MagicQ into Core mode. A Kensington security lock fixing is provided, and the node ships with a DIN rail mount clip, USB A-C cable, screws, and quick start guide.
Key Features
- 2 RDM DMX Ports — Two DMX ports support RDM and configure as input or output.
- Art-Net and sACN — Compatible with any console supporting Art-Net and sACN.
- MagicQ Core Unlock — Unlocks MagicQ PC systems into Core mode over USB-C or network.
- DMX Fallback — Loop fixtures across two ports for redundancy against cable failure.
- Configurable DMX Timings — Adjustable refresh rate, break time, frame time, and MAB.
- Scene Storage — Stores user scenes recordable from incoming Art-Net or sACN data.
- PoE or USB Powered — Powered over PoE on Port 1 or from its USB-C port.
- Multiple Mounting Options — Standalone, truss-mount via M12 receiver, or DIN rail mount.
- Web Server and Display — Configure remotely via web server or locally on the front-panel display.
- Kensington Lock Fixing — Security lock point for installed applications.
Typical Applications
- Compact Installations — DIN rail or standalone Ethernet-to-DMX conversion in tight spaces.
- MagicQ PC Rigs — USB or network interface that unlocks MagicQ Core mode.
- Small Live Setups — Lightweight truss-mounted DMX node for portable systems.
- Architectural Lighting — Low-power node for fixed two-universe distribution.
Technical Specifications
| RDM Direct DMX Ports | 2 (input / output) |
| Network Ports | 1 |
| PoE Input | Yes (Port 1) |
| USB Ports | 1 x USB-C |
| Kensington Security Lock | Yes |
| Power Rating PoE | 42.5-57 VDC, max 7 W |
| Power Rating USB | 5 VDC, 500 mA |
| Protocols | Art-Net, sACN, RDM, ChamNet |
| Configurable DMX Timings | Yes |
| Web Server | Yes |
| DMX Redundancy | Yes |
| User Scene Store | Yes |
| MagicQ Unlock | Core mode (USB-C or network) |
| Dimensions (W x D x H) | 125 x 133 x 44 mm (4.92 x 5.23 x 1.73 in) |
| Weight | 0.85 kg (1.87 lb) |
| Included Accessories | DIN rail clip, USB A-C cable, 3 screws, quick start guide |
Frequently Asked Questions
How many DMX ports does the GeNetix GN2 have?
The GN2 has 2 RDM DMX ports, each configurable as input or output.
What network protocols does the GN2 support?
It supports Art-Net, sACN, RDM, and ChamNet, and is compatible with any console supporting Art-Net and sACN.
How is the GN2 powered?
It can be powered over PoE on Port 1 (42.5-57 VDC, max 7 W) or from its USB-C port (5 VDC, 500 mA).
Does the GN2 unlock MagicQ software?
Yes. It unlocks MagicQ PC systems into Core mode when connected over USB-C or network.
How can the GN2 be mounted?
It can be used standalone, truss-mounted via its M12 receiver, or installed on a DIN rail using the included clip.
Does the GN2 support DMX redundancy?
Yes. It supports DMX Fallback, where fixtures are looped across two ports so the universe keeps running if a single cable breaks.
How is the GN2 configured?
It can be configured locally on the front-panel display, remotely via the onboard web server, or from a ChamSys console.
