Sound Control Technologies RCC-M002-1.0M – DB9-F to Euroblock Serial Cable, 1.0 m
Sound Control Technologies RCC-M002-1.0M – DB9-F to Euroblock Serial Cable, 1.0 m is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Sound Control Technologies RCC-M002-1.0M – DB9-F to Euroblock Seria...
Product Overview
The Sound Control Technologies RCC-M002-1.0M is a 1.0-meter RS-232 serial control cable with a DB9 female connector on one end and a 3-pin 3.81mm Euroblock plug on the other, used to connect DB9 serial ports to the terminal-block COM ports on control processors and AV interfaces. It comes from SCT's multi-use cable line and is the factory accessory for serial control wiring in RemoteCam camera extension installations.
Product Description
Control systems from manufacturers such as Crestron and similar platforms commonly expose RS-232 on 3-pin Euroblock (Phoenix-style) terminal connectors, while SCT modules, codecs, and cameras present DB9 ports. The RCC-M002-1.0M links the two with a factory-terminated cable, removing field termination errors at the Euroblock end and standardizing serial control wiring across rooms. SCT's dealer catalog lists it as a serial control cable, and it is stocked as the spare for SCT extension deployments where camera control passes to a room control processor. The 1.0-meter length suits rack and credenza layouts where the control processor and the serial source are co-located. For DB9-to-DB9 runs, see the companion RCC-M001-1.0M null modem cable.
Key Features
- DB9-F to 3-Pin Euroblock — Connects DB9 RS-232 ports to control processor terminal blocks without field termination.
- Serial Control Cable — Listed by SCT for RS-232 control wiring in camera extension and AV control installations.
- 3.81mm Pitch Euroblock Plug — Seats directly into standard control processor COM port headers.
- 1.0-Meter Length — Sized for rack-mount and credenza control wiring in conference rooms.
- SCT Multi-Use Cable Family — Documented SCT factory accessory and like-for-like replacement.
Technical Specifications
| Specification | Detail |
|---|---|
| Model / SKU | RCC-M002-1.0M |
| Connector A | DB9 female |
| Connector B | 3-pin 3.81mm Euroblock plug |
| Signal | RS-232 serial control |
| Cable Length | 1.0 meter |
| Cable Family | SCT Multi-Use Cables (RCC-M) |
| Unit of Measure | Each |
| Country of Origin | USA / Taiwan |
