Cambridge Sound DS1390 Dynasound Soundmasking / Paging Speaker - 911.0840.900
Cambridge Sound DS1390 Dynasound Soundmasking / Paging Speaker - 911.0840.900 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Cambridge Sound DS1390 Dynasound Soundmasking / Paging Speaker - 91...
Product Overview
The Cambridge Sound DS1390 (part number 911.0840.900) is a Dynasound sound masking and paging speaker with dual, horizontally opposed drivers. The opposed-driver design produces uniform 360-degree dispersion suited to reverberant underfloor cavities and shallow ceiling plenums. An internal 70-volt transformer connects it directly to distributed masking and paging lines.
Product Description
The DS1390 places two performance-engineered drivers back to back with tuned ports, generating even acoustic energy in every direction rather than a single forward lobe. That pattern is what allows it to work in floor cavities as shallow as 1-3/4 inches, where conventional downward-firing masking speakers do not fit. The internal 70-volt transformer supports the long daisy-chained runs typical of distributed sound masking zones, and the same enclosure handles paging signals. An optional mounting bridge adapts the speaker for ceiling plenums; specify the DS1390B when the bridge is required. ETL listing to UL1480 and CSA C22.2 60065 supports code-compliant commercial installation. Pair it with Dynasound generators and plenum cabling from the Cambridge Sound collection at Creation Networks.
Key Features
- Dual Opposed Drivers — performance-engineered drivers with tuned ports deliver uniform 360-degree dispersion.
- Shallow-Cavity Capable — operates in floor cavities as shallow as 1-3/4 inches.
- Internal 70-Volt Transformer — supports long distributed runs for masking and paging zones.
- Bridge Option Available — order the DS1390B variant for ceiling plenum bridge mounting.
- Safety Listed — ETL listed to UL1480 and CSA C22.2 60065 for commercial installation.
- Multi-Signal Use — handles sound masking and paging from a single enclosure.
Technical Specifications
| Specification | Value |
|---|---|
| Model | DS1390 |
| Part Number | 911.0840.900 |
| Driver Configuration | Dual, horizontally opposed drivers with tuned ports |
| Dispersion | Uniform 360-degree |
| Transformer | Internal 70-volt |
| Minimum Cavity Depth | 1-3/4 in |
| Mounting Bridge | Optional (specify DS1390B) |
| Listings | ETL listed to UL1480 and CSA C22.2 60065 |
Specifications sourced from Cambridge Sound vendor data. Unlisted values are omitted rather than estimated.
