C2G CG29304 – DisplayPort to HDMI over Cat5 Extender Kit 328ft
Product Overview
The C2G CG29304 DisplayPort to HDMI over Cat5 Kit extends DisplayPort video from a source computer to an HDMI display up to 328 feet over a single Cat5e, Cat6, or Cat6a cable using HDBaseT technology. Supporting Full HD 1920x1080 at 60Hz with HDCP, 3D, and EDID pass-through, this extender kit is designed for conference rooms, classrooms, and boardrooms where a DisplayPort-equipped PC must feed an HDMI display at distances beyond the native cable limit. A 5-foot DisplayPort cable connects the transmitter to the source; a single Cat cable runs the extension to the HDMI receiver at the display.
Product Description
The CG29304 uses HDBaseT signal transport to carry the converted HDMI signal from the DisplayPort source across structured Cat cable infrastructure. The transmitter accepts a DisplayPort input via the included 5ft DP cable, converts it to HDMI, and sends it over the Cat cable to the receiver. The receiver outputs HDMI directly to the display. EDID pass-through ensures the source negotiates the correct output resolution for the connected display.
Both transmitter and receiver are housed in metal enclosures and are CE certified. Power is supplied via the included 18V adapter. The 328ft extension distance at 1080p makes this kit suitable for large conference rooms, training rooms, and campus-style AV installations where DisplayPort sources must connect to existing HDMI display infrastructure.
Key Features
- DisplayPort to HDMI Conversion and Extension — Converts DisplayPort source output to HDMI and extends the signal up to 328ft over a single Cat5e/6/6a cable.
- 328ft (100m) at 1080p 60Hz — Full HD 1920x1080 at 60Hz over the full HDBaseT extension distance.
- HDBaseT Signal Transport — Uses HDBaseT technology for reliable long-distance signal extension over standard structured cabling.
- HDCP and EDID Pass-Through — Passes HDCP content protection and EDID display capability data through the extension run.
- 3D Support — Compatible with 3D video sources and displays.
- Metal Enclosures — Durable commercial-grade housing on both transmitter and receiver units.
- Included DisplayPort Cable — 5ft DisplayPort cable included for source connection.
- CE Certified — Meets European electromagnetic compliance standards.
Typical Applications
- Conference room DisplayPort PC to HDMI display extension
- Training room and classroom long-run signal distribution
- Boardroom AV rack to wall-mounted display
- Campus AV where DisplayPort sources feed HDMI displays
- Government meeting room permanent AV installation
Technical Specifications
| Input | DisplayPort Female |
| Output | HDMI (via Cat cable to receiver) |
| Extension Standard | HDBaseT |
| Max Distance | 328ft (100m) at 1920x1080 60Hz |
| Max Resolution | Full HD 1920x1080 at 60Hz |
| Cable Required | Cat5e, Cat6, or Cat6a |
| HDCP | Supported |
| EDID Pass-Through | Supported |
| 3D | Supported |
| Power Supply | 18V 1A; Input 100-240V 50-60Hz; included |
| Included Cable | 5ft DisplayPort cable |
| Enclosure | Metal |
| Operating Temperature | 0°C to 50°C; 0–80% RH |
| Certifications | CE |
| Color | Black |
| SKU | CG29304 |
Frequently Asked Questions
- Does this kit support 4K resolution?
No. The CG29304 supports a maximum resolution of Full HD 1920x1080 at 60Hz. For 4K extension, see C2G HDBaseT kits with HDMI 2.0 support at creationnetworks.net.
- What cable type is required?
Cat5e, Cat6, or Cat6a. Shielded solid-conductor cable is recommended for permanent installation and environments with high EMI.
- Does it include the DisplayPort cable?
Yes, a 5ft DisplayPort cable is included to connect the transmitter to the source computer's DisplayPort output.
- Is HDCP supported for protected content?
Yes, HDCP is supported through the full extension run.
- Does it require a power supply at both ends?
The included 18V power adapter powers the system. Refer to the product documentation for which unit the adapter connects to.
- What warranty does C2G provide?
C2G provides a standard commercial warranty. Contact Creation Networks at creationnetworks.net for support.
