C2G 15ft USB 2.0 A to Micro-B Cable M/M - Black (4.6m)
C2G 15ft USB 2.0 A to Micro-B Cable M/M - Black (4.6m) is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
C2G 15ft USB 2.0 A to Micro-B Cable M/M - Black (4.6m)
The USB 2.0 A to Micro-B cable provides reliable connectivity for devices like smartphones, tablets and PC peripherals. This cable is ideal for charging Android phones and transmitting data at speeds up to 480 Mbps. The connections are plug and play, making it the perfect cable for travel or while on the go.
Features and Benefits
- Data transfer speeds up to 480 Mbps
- Perfect replacement or spare cable
Electrical Specifications
- Voltage Rating: 30V
- Conductor Resistance: at 20°C Max
- 28 AWG: 232
- /km; 24 AWG: 93.25
- /km
- Insulation Resistance: 10M
- /km min at 20°C dc 500V
- Time Delay: 5.2ns/m(Max)
- Impedance: 90±15%
- Propagation Delay Skew: 100ps (Full-/High-Speed only)
- Attenuation (Full-/High- Speed only): 0.064MHz: 0.08dB; 0.256MHz: 0.11dB; 0.512MHz: 0.13dB; 0.772MHz: 0.15dB; 1MHz: 0.20dB; 4MHz: 0.39dB; 8MHz: 0.57dB; 12MHz: 0.76dB; 24Mhz: 0.95dB; 48MHz: 1.35dB; 96MHz: 1.90dB; 200MHz:
- Differential Impedance: Cable @ 200ps Tr(10-90%) 90±7
- Intra-Pair Skew: 15ps/m @ 200ps Tr(10-90%)
- Attenuation/Insertion Loss: 1.5dB/2M@0.1GHz; 5.0dB/2M@1.25 GHz; 7.5dB/2M@2.5Ghz; 25dB/2M@7.5GHz
- Differential to Common mode(max):20dB/cable@0.1~7.5GHz
- NEXT: 32dB@0.1GHz; 32dB@2.5GHz; 23dB@3.0GHz; 23dB@7.5GHz
Physical Specifications
- Minimum Bend Radius: 47mm
- Tensile Strength: Unaged: 1500PSI min Aged: 70%min
- Elongation: Unaged: 100% min, Aged: 65%
- Deformation test: Max 50%
- Flame Test: PASS VW-1
- Shield Type/Braid Coverage: 65%
- Shield Type/Braid Construction: 15/5/0.10mm TC
- Jacket Material & Thickness: PVC 0.38mm Min AVG
- Drain Wire AWG & Construction: 28 AWG & 7/0.12mm TC
- Product is CE Marked and Conforms to 2011/65/EU ROHS 2
- Testing: 100% test for short/open: 10M OHM Insulation Resistance (300 DC)
