BrightSign XD236 | 4K PoE+ Digital Signage Player — Series 6 Standard I/O (Touch-Screen + CMS Bundle)
BrightSign XD236 | 4K PoE+ Digital Signage Player — Series 6 Standard I/O (Touch-Screen + CMS Bundle) is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
BrightSign XD236 | 4K PoE+ Digital Signage Player — Series 6 Standa...
BrightSign XD236 — Exceptional 4K Visuals, Deployable Anywhere
The BrightSign XD236 (Series 6) leverages the flexibility of Power over Ethernet (PoE+) to deploy high-performance 4K graphics and stream profoundly captivating 4K video — anywhere. Offered here as a touch-screen + CMS bundle for Android and Windows displays, it pairs the reliability of the self-healing BrightSignOS™ with a content management system to get interactive signage live faster.
Key Features
- Stellar 4K — dual 10-bit 4K at 60p decoding, 4K video rotation, and 10-bit HDR
- 4K image & graphics resolution with smooth full-screen 2D WebGL motion
- AI-ready integrated Neural Processing Unit (NPU) for edge AI without compromising video or graphics
- Power over Ethernet (PoE+) powers the player — deploy anywhere with a single cable
- Expandable internal storage via optional M.2 PCIe NVMe SSD (256GB); secure internal microSD
- Bundled CMS for Android & Windows touch-screen deployments
- Free bsn.Control remote management; included 5-year warranty (parts & labor)
The BrightSign Advantage
- Deploy high-performance and creative experiences anywhere using the flexibility of PoE+
- Stellar 4K or dual 4K video, ideal for on-screen and projected displays, with 10-bit HDR support
- Deploy immersive and captivating 4K graphics
- Expandable internal storage via an M.2 interface SSD storage option
- Operate with unparalleled reliability, security, and sustainability on BrightSignOS™
- Reduce total cost of ownership with complimentary remote player management and controls
- Achieve CMS choice flexibility with a trusted global network of leading integrated partner solutions
- Leverage an integrated Neural Processing Unit (NPU) which enables BrightSign players to run powerful AI applications without compromising on video or graphics performance
Typical Applications
- Conference, huddle & meeting rooms — room-status boards, schedules, and welcome screens that complement video-conferencing platforms including Zoom Rooms, Microsoft Teams Rooms, Google Meet, and Cisco Webex.
- Retail & QSR — promotional displays, digital menu boards, and point-of-purchase signage.
- Video walls & projected displays — dual-4K visuals and immersive 4K graphics for centerpiece installations.
- Corporate lobbies & campuses — wayfinding, live dashboards, and internal communications.
- Transportation, museums & public spaces — PoE+ deployment flexibility for informational signage.
Ports & Connectivity (XD236 — Standard I/O)
- HDMI 2.0a video output
- PoE+ Gigabit Ethernet plus 10/100 Ethernet port
- Audio (3.5mm) — analog & SPDIF digital; IR (3.5mm); bi-directional GPIO (12-pin Phoenix)
- Internal microSD socket, M.2 E-Key Wi-Fi/Bluetooth slot, and M.2 PCIe slot for optional NVMe SSD
- Locking power supply (12V/3A); real-time clock (14-day life)
- USB-C, USB-A, and serial are available on the Expanded-I/O XD1036.
Technical Specifications
| Spec | XD236 |
| Series / I/O package | Series 6 / Standard |
| NPU (AI-ready) | Yes |
| 4K video decoding | Dual 10-bit at 60p |
| Full HD video decoding | Dual at 60p |
| HDR support | 10-bit |
| Image & graphics resolution | 4K |
| 4K video codecs | H.265/HEVC (60p), H.264/AVC (max 30p), VP9 |
| HTML5 performance | Smooth full-screen 2D WebGL motion (HTML5, CSS, JS, SVG, WebGL, Chromium) |
| Power | PoE+ and 12V/3A locking supply |
| Storage | Internal microSD; optional M.2 PCIe NVMe SSD (256GB) |
| Images / Audio | BMP, JPEG, PNG / MP2, MP3, AAC, WAV |
| Operating temperature | 0°C to 50°C |
| Dimensions (W × D × H) | 205 × 185.9 × 19.2 mm |
| Weight | 0.59 kg (1.3 kg shipping) |
| Mounting / Approvals | Built-in wall mounting; multi-country regulatory |
| Warranty | 5-year, parts & labor |
XD236 vs XD1036 — Which Should You Choose?
Both Series 6 XD players share the same dual-4K engine, AI-ready NPU, PoE+, 10-bit HDR, optional NVMe SSD, and 5-year warranty. The difference is the I/O package and interactivity.
| Feature | XD236 (this player) | XD1036 |
| I/O package | Standard | Expanded |
| HTML5 performance | Smooth full-screen 2D WebGL | Responsive multi-touch 2D WebGL |
| USB-C / USB-A ports | — | Yes |
| Serial port (3.5mm) | — | Yes |
| Dual 4K · PoE+ · NPU · 10-bit HDR · optional NVMe SSD · 5-yr warranty | Yes | Yes |
| Best for | Premium full-screen 4K playback signage | Touch- and peripheral-rich interactive deployments |
Built on BrightSignOS™ — The Power of Purple
BrightSignOS™ is the only purpose-built signage operating system: secure (runs a single signed signage application), reliable (persistent self-healing protocols and remote management), superior (optimized video and motion graphics), and sustainable (low power, long life-cycle support, free updates) — lowering total cost of ownership over the life of your deployment.
Why Buy from Creation Networks
As an authorized BrightSign reseller with in-house AV expertise, we help you spec the right player, accessories, and software for your deployment. Pricing is subject to change — contact us for volume and project quotes.
Frequently Asked Questions
Is this a genuine BrightSign product?
Yes. Creation Networks is an authorized BrightSign reseller — every player is genuine and backed by BrightSign's manufacturer warranty.
What's included in this bundle?
This listing pairs the BrightSign XD236 player with a content management system (CMS) for Android & Windows touch-screen deployments. Contact us to confirm the exact bundle configuration for your project.
Is the XD236 powered by PoE?
Yes. The XD236 supports Power over Ethernet (PoE+) and also ships with a 12V/3A locking power supply.
What's the difference between the XD236 and XD1036?
Both share the same Series 6 dual-4K engine, NPU, PoE+, and HDR. The XD236 is the Standard I/O model; the XD1036 adds an Expanded I/O package with USB-C, USB-A, serial, and responsive multi-touch for peripheral-heavy interactive deployments.
Can you help me choose the right player or get volume pricing?
Yes — our in-house AV team helps you spec the right player, accessories, and software, and we offer project and volume quotes. Contact us.
