Bose FreeSpace 360-P Series II – Commercial In-Ground Landscape Loudspeaker

Product Overview

The Bose FreeSpace 360-P Series II is a commercial-grade in-ground loudspeaker engineered for landscape audio installations requiring omnidirectional sound coverage at grade level. Designed for permanent outdoor installation, the 360-P II delivers 360-degree horizontal sound dispersion from a single buried enclosure, making it the primary choice for commercial landscape audio in corporate campuses, retail courtyards, hospitality outdoor spaces, and house of worship outdoor areas. It is fully compatible with 70 V and 100 V distributed audio systems and supports direct 8-ohm operation, integrating with the same amplification infrastructure used for indoor commercial audio distribution.

Product Description

The Bose FreeSpace 360-P Series II uses an upward-firing driver configuration with a conical deflector to achieve full 360-degree horizontal dispersion. This design approach allows a single speaker to cover a wide circular listening area without the hot spots or dead zones common in directional landscape speaker arrays. The speaker projects sound outward at a low angle relative to the ground plane, providing even coverage across a radius appropriate for commercial landscape audio zones.

The enclosure is constructed from UV-stabilized ABS with a stainless steel grille, rated for permanent in-ground installation in soil or landscaped beds. The weatherproof construction meets IP55 ingress protection requirements, protecting the driver and transformer from moisture, insects, and soil particulate intrusion. The Series II version features an improved driver assembly and refined acoustic tuning compared to the original 360-P, with extended low-frequency output for better music reproduction in open outdoor environments.

Installation requires a standard PVC conduit connection at the base of the enclosure for cable entry and drainage. The speaker is designed to be set into a pre-dug hole with the top grille surface flush or slightly above grade. A built-in 70 V / 100 V transformer with selectable wattage taps allows direct connection to commercial distributed audio amplification without additional transformer hardware. The black grille top blends with mulch, soil, and ground cover finishes common in commercial landscape design.

The FreeSpace 360-P II is a standard specification item for commercial AV integrators designing outdoor distributed audio for corporate campuses, resort pools, retail plazas, and hospitality properties. For landscape audio system design, zone planning, and project pricing, contact the commercial AV team at creationnetworks.net.

Key Features

• 360-Degree Omnidirectional Coverage — Upward-firing driver with conical deflector delivers uniform horizontal dispersion, eliminating dead zones in landscape audio zones.
• In-Ground Permanent Installation — Designed for burial in soil or landscaped beds with flush or slightly above-grade mounting for a clean, unobtrusive aesthetic.
• IP55 Weather Protection — UV-stabilized ABS enclosure and stainless steel grille protect against moisture, insects, and outdoor environmental exposure.
• Built-In 70 V / 100 V Transformer — Selectable wattage taps allow direct connection to commercial distributed audio amplification infrastructure.
• 8-Ohm Direct Drive Compatible — Supports low-impedance operation for use with zone controllers and direct-drive amplifiers.
• Series II Improved Driver — Updated driver assembly and acoustic tuning deliver extended low-frequency output compared to the original 360-P for better outdoor music reproduction.
• PVC Conduit Cable Entry — Standard conduit connection at base simplifies underground cable routing in commercial landscape construction.
• Commercial-Grade Construction — Designed for unattended, continuous-duty outdoor operation in commercial environments without seasonal removal.

Typical Applications

• Corporate campus outdoor landscape audio
• Retail plaza and outdoor commercial meeting space audio
• Hospitality pool deck and courtyard distributed audio
• House of worship outdoor campus audio
• Government space and municipal plaza background music
• Multi-purpose outdoor event space audio distribution

Technical Specifications

Frequently Asked Questions

Does the FreeSpace 360-P II need to be removed for winter?

No. The 360-P II is rated for permanent in-ground installation and is designed to withstand outdoor temperature extremes from -20°C to 60°C. It does not require seasonal removal in most North American climates.

Is the 360-P II compatible with standard 70 V distributed audio amplifiers?

Yes. The built-in transformer supports 70 V and 100 V distributed audio with selectable wattage taps (5 W, 10 W, 20 W, 40 W), making it compatible with any commercial 70 V amplifier from Crown, QSC, Bose, or similar manufacturers.

How deep does the hole need to be for installation?

The 360-P II requires a hole approximately 10 to 11 inches deep to allow the grille surface to sit at or slightly above grade. A 3/4-inch PVC conduit trench is required for cable routing from the speaker to the amplifier location.

How many 360-P II speakers are needed per coverage zone?

Spacing depends on background noise levels and the desired SPL. In typical commercial landscape settings, speakers are spaced 15 to 25 feet apart for background music applications. A Creation Networks commercial AV designer can assist with zone layout and system sizing.

Can the 360-P II be used near a pool or irrigation zone?

Yes. The IP55 weather rating covers moisture and water jet exposure from most directions. The speaker is suitable for installation near pools, fountains, and irrigation zones, provided the conduit cable entry is properly waterproofed.

Is this speaker compatible with Bose ControlSpace or FreeSpace IZA systems?

Yes. The 360-P II operates on standard 70 V / 100 V or 8-ohm connections and is compatible with Bose FreeSpace IZA integrated zone amplifiers, ControlSpace EX/ESP processors, and any third-party commercial amplification platform.

What warranty does the FreeSpace 360-P Series II carry?

Bose Professional provides a 5-year limited warranty. For commercial landscape audio project support, system design, and warranty service, contact Creation Networks at creationnetworks.net.
