Blaze Audio PowerZone Connect 3004 - Networkable 4-Channel Install Power Amplifier - LBX-888-004

Product Overview

The Blaze by Sonance PowerZone Connect 3004 is a networkable install power amplifier delivering 3000W across four channels in a 2U rack-mount chassis — engineered for permanent distributed commercial audio installations where multi-zone DSP control and remote management are priorities. Without the Dante option, it connects to facility AV systems via balanced analog inputs and a 10/100 Ethernet port for PowerZone Control software access, making it a cost-effective commercial audio matrix amplifier for integrators who don't require network audio transport. Onboard matrix DSP handles all per-channel signal processing, eliminating the need for a dedicated outboard processor. The 3004 is a practical, high-output solution for boardrooms, training facilities, houses of worship, and any commercial venue requiring dependable multi-zone amplification.

Product Description

Rated at 4 x 750W into 4Ω, the PowerZone Connect 3004 provides substantial output power for multi-zone commercial installations. Its Class-D topology delivers high efficiency, reducing heat dissipation and long-term operating costs compared to traditional linear amplifier designs. The onboard matrix DSP includes per-channel parametric EQ, limiting, delay, and crossover filtering, giving integrators the signal processing tools needed to tune each zone without adding a standalone DSP unit to the rack.

Network management is handled via a 10/100 Ethernet connection and PowerZone Control software, which provides a web and app-based interface for remote configuration, monitoring, and preset management. This means facility managers or remote AV technicians can adjust system settings, switch presets, or monitor amplifier status from any device on the network — without physical access to the rack. Balanced XLR/TRS combo inputs accept analog signals from any professional mixer or DSP, and Euroblock speaker outputs ensure secure, permanent terminations throughout the installation.

The 3004 is the four-channel, non-Dante counterpart to the 3004D, making it the right choice for facilities that route audio over analog infrastructure or are not yet deploying Dante. It ships ready for 2U rack mounting and operates on a universal 100–240V power supply, supporting international installations without modification. For AV integrators looking for a high-output, networkable Class-D amplifier for commercial installation, the 3004 is available through Creation Networks' Blaze by Sonance catalog.

Key Features

• 3000W Total Output Power — Four channels at 750W each into 4Ω handles high-SPL commercial environments with authority.
• Onboard Matrix DSP — Per-channel EQ, limiting, delay, and crossover processing built in, no external signal processor required.
• PowerZone Control Software — Web and app-based remote management for configuration, monitoring, and preset recall over standard IP networks.
• 10/100 Ethernet Connectivity — Integrates into facility IT networks for centralized AV system management without proprietary hardware.
• Class-D Amplifier Topology — High-efficiency design reduces power consumption and thermal load in always-on commercial installations.
• Balanced XLR/TRS Combo Inputs — Accepts professional line-level signals with strong noise rejection for clean signal integrity over long cable runs.
• Euroblock Speaker Outputs — Tool-terminated, vibration-resistant connections designed for reliable permanent installation.
• 2U Rack-Mount Form Factor — Compact chassis preserves rack space in equipment rooms and closets.
• Universal Power Supply (100–240V) — Suitable for domestic and international installations without additional hardware.

Typical Applications

• Corporate boardrooms and conference rooms
• House of worship main auditorium and overflow areas
• Multi-zone commercial meeting spaces
• Training rooms and education facilities
• Auditoriums and performing arts centers
• All-hands rooms and town hall spaces
• Multi-purpose venues requiring zoned distributed audio
• Hospitality venues and commercial public-address systems

Technical Specifications

For complete specifications, refer to the official Blaze Audio datasheet.

Frequently Asked Questions

What is the difference between the PowerZone Connect 3004 and the 3004D?

The 3004D includes Dante network audio transport, allowing audio signals to be routed over IP infrastructure. The 3004 uses analog balanced inputs only and is the appropriate choice when Dante is not part of the system design. Both share identical output power, DSP capabilities, and PowerZone Control network management.

Can the 3004 be upgraded to Dante after purchase?

Dante functionality is a hardware feature of the 3004D model and cannot be added to the 3004 after purchase. If Dante is anticipated in future system expansions, specifying the 3004D at the outset is recommended.

How does PowerZone Control software connect to the amplifier?

PowerZone Control connects over a standard IP network via the amplifier's 10/100 Ethernet port. The software is available as a web interface and mobile app, allowing configuration and monitoring from any device on the network without physical access to the rack.

What DSP functions are available per channel?

Each channel includes parametric EQ, high-pass and low-pass filtering, delay, and limiting. All parameters are configured and stored via PowerZone Control, and multiple presets can be saved for different operating scenarios.

Does the 3004 support 70V or 100V distributed speaker systems?

Refer to the official Blaze Audio datasheet for supported load configurations including constant-voltage operation. Contact a Creation Networks representative for guidance on matching the amplifier to your specific speaker system design.

Is the PowerZone Connect 3004 suitable for a standalone single-zone installation?

Yes. While the 3004 is designed for multi-zone deployments, individual channels can be configured independently for single-zone applications where high output power is the primary requirement.

What warranty and support are available?

Blaze by Sonance products include manufacturer warranty coverage. Creation Networks provides pre-sale specification support and post-sale assistance for commercial AV integrators.
