Blaze Audio CCA10i-BA-W – Scalable 20° Bi-Amped Line Array Cabinet, White

Product Overview

The Blaze Audio CCA10i-BA-W is a bi-amped constant curvature array cabinet in white finish, designed for scalable commercial sound reinforcement in environments where a white aesthetic is specified. With a 20-degree vertical splay per cabinet, it enables integrators to build flown or ground-stacked arrays scaled precisely to venue geometry and coverage requirements. It is the white-finish variant of the CCA10i line array cabinet and functions as the core of the Blaze by Sonance CCA Series system, pairing with the BL118SSi-B or BL218SSi-B subwoofers and the CCA10i-RigGrid rigging system. Available from Creation Networks.

Product Description

The CCA10i-BA-W brings the full performance of the Blaze by Sonance CCA10i line array system to installations where a white-finish loudspeaker is specified — including houses of worship with bright interiors, corporate auditoriums, hospitality venues, and multi-purpose rooms where hardware must blend with the architecture. Each cabinet contributes a 20-degree vertical arc to the array, allowing array curvature to be tailored to the room's geometry by adjusting cabinet count. The bi-amped design provides independent amplification of the HF and LF sections within each cabinet, delivering the gain structure control and headroom required for high-output commercial applications. Rigging for flown installations requires the CCA10i-RigGrid (sold separately), which is available in white (MCH-888-006) to maintain a consistent finish across the full system installation. The CCA10i-BA-W pairs with the BL118SSi-B or BL218SSi-B sub-bass companion subwoofers for complete low-frequency extension. All system components are engineered together, simplifying specification, commissioning, and long-term system maintenance for AV integrators. This cabinet is also available in black — see the CCA10i-BA-B at Creation Networks for black-finish installations.

Key Features

• 20° Constant Curvature Design — Each cabinet contributes a fixed 20-degree vertical arc, enabling precise array curvature matched to venue geometry.
• Bi-Amped Configuration — Independent HF and LF amplifier inputs per cabinet allow optimized gain structure and headroom across the operating bandwidth.
• Scalable Array System — Add or remove cabinets to adjust vertical coverage, throw, and output to meet specific venue requirements.
• CCA10i Ecosystem Integration — Engineered to work with BL118SSi-B or BL218SSi-B subwoofers and the CCA10i-RigGrid-W rigging system.
• Flown or Ground-Stack Deployment — Compatible with the white CCA10i-RigGrid-W for suspended arrays; also suitable for ground-stack configurations.
• White Architectural Finish — Clean white exterior integrates into bright commercial interiors, worship spaces, and corporate environments.
• Commercial-Grade Construction — Built for continuous operation in professional commercial environments.
• Complete System Solution — Part of the Blaze by Sonance CCA Series, with matched subwoofers and rigging accessories for a complete install solution.

Typical Applications

• House of worship
• Auditorium
• Multi-purpose room
• Commercial meeting space
• Training room

Technical Specifications

Refer to the official Blaze by Sonance datasheet for complete technical specifications including frequency response, SPL ratings, impedance, and power handling data.

Frequently Asked Questions

What amplifier is required for the CCA10i-BA-W?
The CCA10i-BA-W requires bi-amp operation — one amplifier channel per frequency band per cabinet. Consult the Blaze by Sonance datasheet for impedance and power handling specifications. DSP processing is required for crossover and system alignment.

How many CCA10i-BA-W cabinets are needed for my installation?
Array size depends on vertical coverage angle, room geometry, throw distance, and SPL targets. Contact Creation Networks for system design support specific to your project.

What rigging hardware is required for a flown white installation?
Flown white-finish installations require the CCA10i-RigGrid-W (SKU: MCH-888-006), available at Creation Networks, to maintain a consistent all-white system appearance.

Which subwoofers are compatible with the CCA10i-BA-W?
The CCA10i-BA-W is designed to pair with the BL118SSi-B (single 18") or BL218SSi-B (dual 18") companion subwoofers, available at Creation Networks.

Is the CCA10i-BA-W available in black?
Yes. The black-finish version is the CCA10i-BA-B (SKU: FGM-888-001), also available at Creation Networks.

What warranty does Blaze by Sonance provide?
Contact Creation Networks for current warranty terms and authorized service information.

Where can I get system design and technical support?
Creation Networks provides full system design and technical support for Blaze by Sonance CCA Series installations. Contact the team at creationnetworks.net.
