Blackmagic Design Videohub Mini 8x4 12G – Compact SDI Router
Blackmagic Design Videohub Mini 8x4 12G – Compact SDI Router is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Blackmagic Design Videohub Mini 8x4 12G – Compact SDI Router
Product Overview
The Blackmagic Design Videohub Mini 8x4 12G is a compact SDI video router with 8 inputs and 4 outputs and full 12G-SDI support, routing Ultra HD video up to 2160p60 over a single cable. With Ethernet IP control and a small rack-mountable form factor, it's well suited to small-to-medium production setups that need fast, reliable switching between multiple sources and destinations.
Product Description
The Videohub Mini 8x4 12G provides eight 12G-SDI inputs and four 12G-SDI outputs, supporting SD, HD, 3G, 6G, and 12G-SDI signals up to 2160p60 on a single cable. It's controlled over Ethernet (IP control) and integrates with the Videohub software and compatible hardware control panels, giving you centralized, remote routing management in studios, OB trucks, and live event setups. The compact rack-mountable chassis with an internal power supply installs easily, and it scales into larger Videohub systems as routing needs grow.
Key Features
- 8×4 12G-SDI routing — Eight 12G-SDI inputs and four 12G-SDI outputs.
- Up to 2160p60 — Ultra HD over a single cable.
- Multi-rate SDI — Supports SD, HD, 3G, 6G, and 12G-SDI.
- Ethernet IP control — Works with Videohub software and control panels.
- Compact chassis — Rack-mountable with an internal power supply.
- Scalable — Integrates into larger Videohub systems.
Typical Applications
- Broadcast studio — Compact 12G routing where rack space is limited.
- Auditorium — Small-footprint source routing for live events.
- House of worship — Routing multiple cameras and playback sources.
Technical Specifications
| Model | VHUBSMTK12G0804 |
| Inputs | 8× 12G-SDI |
| Outputs | 4× 12G-SDI |
| Max Resolution | Up to 2160p60 (Ultra HD) |
| Video Standards | SD, HD, 3G, 6G, 12G-SDI |
| Control | Ethernet (IP control) |
| Power | Internal power supply |
Frequently Asked Questions
What's the routing capacity?
Eight 12G-SDI inputs to four 12G-SDI outputs, supporting up to 2160p60.
What SDI formats does it handle?
SD, HD, 3G, 6G, and 12G-SDI over a single cable.
How is it controlled?
Over Ethernet via IP control, using the Videohub software or compatible control panels.
Can it scale into a larger system?
Yes — it integrates with other Videohub routers for expanded routing needs.
